Specifications
Place of Origin :
Shanghai, China
Brand Name :
YASEN
Warranty :
1 Year
After-sales Service Provided :
Video technical support, Field installation, commissioning and training, Free spare parts, Online support, Engineers available to service machinery overseas
Power :
0.75-2.2
Weight :
1500kg-4350kg
Size :
4040x2410x1420mm
No. of roller :
1-5
Max Feeding Width :
2500mm,3000mm,3300mm
Ironing speed :
0-25m/min
Motor Power :
0.75kw-2.2kw
heating way :
steam or electric
Roller material :
Stainless steel
Description :
ironing machine/ Flatwork Ironer
Usage :
Hotel Used Commercial Laundry Equipment
Certification :
CE; ISO
Packaging Details :
WOODEN PACKAGE
Port :
Shanghai port
Supply Ability :
50 Set/Sets per Month
Price :
$6,500.00/sets >=1 sets
MOQ :
1pc
Description
Flatwork Ironing Machine speed Laundry Equipment 0.75-2.2 Power 1500kg-4350kg Capacity
Products Description
Flatwork Ironing Machine speed Laundry Equipment 0.75-2.2 Power 1500kg-4350kg Capacity
Use:
Y series roller automatic flat-work ironing machine is new product developed by our company with Sino-foreign technology.It is suitable for star-level hotel.restaurant,hospital,rallway,larger washing center,washing-dyeing factory,industry-mining enterprise and so on. It is used to make ironing and from-finishing for flat fabrics,like bedsheet,bedcover and table cloth after washing and extracting.
Short introduction:
Efficiently ironing the fabrics with duplex and no trace,to ensure high-quality ironing effect.
This equipment is made of high-precision 304 stainless steel drum,long service life.
Frequency conversion drives,users can adjust ironing speed depend on different fabrics,improve the ironing efficiency. Programmable computer controlled,multi-lanuage control panel,large screen LCD,man-machine interface,easy to operate.
Using frequency-conversion motor,reducer,chains transmission,run smoothly;equipped buffer,auto adjustment conveying system,no need guide strips,precise convey.
Safe electrical-pneumatic design,can stop machine in emergency,to ensure operators safety.
After sales service:
The whole machine has been guaranteed for 1 years.
Providing lifelong technical support.
Guarantee of spare parts supply.
Engineers available to service machinery overseas.
Installation and Test
(1)Free technical train at factory
(2)Free technical guide through network
(3)On-site service under contract
Warranty:
Main spare parts(except consumable accessories) under ONE YEAR Warranty with defects from manufacturer by free shipping
Product Parameters
Attributes
Y-2500I
Y-3000II
Y-3300III
Max Feeding Width(mm)
2500
3000
3300
Rolls Quantity
1
2
3
Roll Diameter(mm)
800
800
800
Ironing Speed(m/min)
0-9
0-18
0-25
Electric Heating Power(kw)
27
64
96
Steam Presure(Mpa)
0.3--0.6
0.3--0.6
0.3--0.6
Steam Consumption(kg/h)
120
250
320
Steam lnlet(lnch)
G1.5"
G1.5"
G1.5"
Drain Outlet(lnch)
G1.5"
G1.5"
G1.5"
Gas Consumption(m³/h)
6m³
12m³
Gas lnlet(lnch)
G1.5“
G1.5“
Rated-Voltage(V)
220/380/415
220/380/415
3P/380/50HZ
Motor Power(kw)
0.75
1.5
2.2
Dimension(L.W.H) (mm)
3540x1470x1420
4040x2410x1420
4340x3350x1420
N.W.(kg)
1500
3050
4350
