Description


XHYZ1668 On-Load Tap Switch Tester Output Current 0.2A Suitable for Various Applications


Introduction

The on-load tap-changer, being the sole moving component connected to the transformer circuit, has increasingly become a focal point for detection. This instrument is designed to measure the transition waveform, transition time, transient resistance value of the on-load tap changer of a transformer, as well as three-phase consistency. It is highly intelligent, featuring an all-English menu with simple operation. Compact in size, lightweight, and with strong anti-interference capabilities, this instrument significantly reduces the labor intensity for on-site workers. It is an ideal tool for power generation and supply units, as well as transformer manufacturers, to ensure safe production and enhance product quality.

Features

  1. The instrument has a large output current and is light in weight;
  2. Test YN, Y, △ transformers, and the resistance value can be displayed directly without conversion;
  3. It can be measured with and without windings;
  4. Waveform display automatically adjusts the amplitude of resistance and time value according to the sampled value
  5. It has a complete protection circuit and strong reliability;
  6. Large 7-inch LCD display, convenient for on-site operation;
  7. 500 sets of data can be automatically saved internally.

Technical indicators

Output current
 1.0A, 0.5A
Test range Transition resistance: 0.5Ω~20Ω(1.0A), 0.5Ω~40Ω(0.5A)
Transition time: 0 ~ 250ms
Test accuracy Transition resistance: ± (5% reading + 3 words)
Transition time: ± (0.1% reading + 3 words)
Storage mode U disk storage, local storage
Ambient temperature -10 ° C ~ 50 ° C
Ambient humidity ≤85%RH
Working power supply AC220V±10%
Power frequency 50±1Hz
Size 345 × 295 × 175mm
Weight 5kg


Packing list
