Specifications
Model NO. :
XHDQ703
Power :
Electricity
Certification :
CE
Customized :
Customized
Color :
Black
Transport Package :
Exported Wooden Case
Specification :
285mm*85mm*56mm
Trademark :
XZH TEST
Origin :
China
Supply Ability :
2000PCS/Year
Customization :
Available
After-sales Service :
After Sale Serive
Warranty :
12 Months
Description
Customization Xhdq703 Single Clamp Earthing Ground Resistance Tester 285mm*85mm*56mmCustomization Xhdq703 Single Clamp Earthing Ground Resistance Tester 285mm*85mm*56mm

Main features:
  1. Ground resistance tester and loop resistance tester.
  2. More safer and faster when test loop resistance system, No need to disconnect the ground wire and
    without auxiliary electrode.
  3. Short boot time, Self just 0.5 seconds, boot instantaneously.
  4. Automatically identify Interference signal, automatic transmission.
  5. Sound and light alarms, RS232 interface
Main Specifications
  1. :
  2. : 0.01-1200Ω
  3. Resistance Resolution: 0.001Ω
  4. Resistance Accuracy: ±1%±0.01Ω
  5. Data memory : 99 Sets
  6. Alarm Threshold Setting Range Resistance: 1-199Ω
  7. Working Temperature and Humidity: -20°C-55°C; 20%RH-90%RH
  8. LCD Screen: 4 Digits LCD display; Screen L×W: 47mm×28.5mm
  9. Clamp Size: 65mm×32mm
  10. Clamp Opening: Extent 32mm
  11. Weight: 1160g (With batteries)
  12. Dimension : 285mm×85mm×56mm
Testing range and accuracy
Measurement mode testing range resolution Accuracy
0.010Ω-0.099Ω 0.001Ω ±(1%+0.01Ω)
0.10Ω-0.99Ω 0.01Ω ±(1%+0.01Ω)
1.0Ω-49.9Ω 0.1Ω ±(1%+0.1Ω)
50.0Ω-99.5Ω 0.5Ω ±(1.5%+0.5Ω)
100Ω-199Ω 1Ω ±(2%+1Ω)
200Ω-395Ω 5Ω ±(5%+5Ω)
400-590Ω 10Ω ±(10%+10Ω)
600Ω-880Ω 20Ω ±(20%+20Ω)
900Ω-1200Ω 30Ω ±(25%+30Ω)
Current 0.00mA -9.95mA 0.05mA ±(2.5%+1mA)
10.0mA -99.0mA 0.1mA ±(2.5%+5mA)
100mA -300mA 1mA ±(2.5%+10mA)
0.30A-2.99A 0.01A ±(2.5%+0.1A)
3.0A-9.9A 0.1A ±(2.5%+0.3A)
10.0A-20.0A 0.1 A ±(2.5%+0.5A)


Technical specifications

Resistance testing range 0.01Ω-1200Ω
Resistance resolution 0.001Ω
Current resolution 0.05mA
Alarm Threshold Setting Range Resistance 1-199Ω
Current 1-499mA
Power 6VDC(4 PCS of LR6 Alkaline batteries)
Working Temperature and Humidity -20ºC-55ºC;10%RH-90%RH
Display 4 Digits LCD display; Screen L×W: 47mm×28.5mm
Clamp Size 65mm×32mm
Clamp Opening Size Extent 32mm
Weight 1160g (With battery)
Dimension 285mm×85mm×56mm
Explosion-proof mark Exia II BT3 Ga
Protection level Double insulation
Structural features Clamp CT
Shift Automatic gear shift
External magnetic, electric field < 40A/m; < 1v/m
Single measurement time 0.5 sec
Resistance measurement frequency > 1 KHz
Current frequency under test 50/60Hz automaticly
