Certificate XHJB612 Xzh Test Supply Transformer Single Phase Relay Protection Tester
Certificate XHJB612 Xzh Test Supply Transformer Single Phase Relay Protection Tester
Certificate XHJB612 Xzh Test Supply Transformer Single Phase Relay Protection Tester
Certificate XHJB612 Xzh Test Supply Transformer Single Phase Relay Protection Tester
Certificate XHJB612 Xzh Test Supply Transformer Single Phase Relay Protection Tester
Certificate XHJB612 Xzh Test Supply Transformer Single Phase Relay Protection Tester
Certificate XHJB612 Xzh Test Supply Transformer Single Phase Relay Protection Tester
Certificate XHJB612 Xzh Test Supply Transformer Single Phase Relay Protection Tester
Certificate XHJB612 Xzh Test Supply Transformer Single Phase Relay Protection Tester
Certificate XHJB612 Xzh Test Supply Transformer Single Phase Relay Protection Tester
Certificate XHJB612 Xzh Test Supply Transformer Single Phase Relay Protection Tester
Certificate XHJB612 Xzh Test Supply Transformer Single Phase Relay Protection Tester
Specifications
Brand Name :
XZH TEST
Model Number :
XHJB612
Certification :
CE/ISO
Place of Origin :
China
MOQ :
1 unit
Payment Terms :
T/T
Supply Ability :
100 Pieces /Year
Delivery Time :
5-8 work days
Packaging Details :
wooden packaging
Model NO. :
XHJB612
Trademark :
XZH TEST
Origin :
China Xi′an
HS Code :
854320100
Customization :
Available
After-sales Service :
Warranty Certificate
Warranty :
Warranty Certificate
Description

Product Description

I.Main functions
☆Requires single-phase AC220V power supply, using beautiful and elegant PVC panels
☆Has mA output, which can meet polarization, signal and other relay tests
☆Built-in digital millisecond meter with start and stop meter terminals
☆With sound and light prompts for action contacts, etc.
☆Specially made high-strength aluminum alloy chassis, easy to carry and transport
☆The panel operation is simple and easy to master, and the wiring is clear, making it convenient for on-site work.
Certificate XHJB612 Xzh Test Supply Transformer Single Phase Relay Protection Tester


II.Main technical indicators
1. Power supply: AC220V
2. Output:
Main circuit:
AC output: Current: 0-5A 0-50A 0-150A Voltage: 0-250V continuously adjustable
DC output: Voltage: 0-250V Current: 0-20A 0-500mA
Time measurement: 0-99.99S
3. Measuring range
Voltage: 0~500V 0.5%RD±2d
Current: 0~5A 0~50A 0~150A 0.5%RD±2d
Measurement time range: 0.01~99.99S

Certificate XHJB612 Xzh Test Supply Transformer Single Phase Relay Protection Tester
