Specifications
Brand Name :
XZH TEST
Model Number :
XHJS401A
Certification :
CE/ISO
Place of Origin :
China shanxi
MOQ :
1 Unit
Payment Terms :
T/T
Supply Ability :
1000 units per year
Delivery Time :
5-8 work days
Packaging Details :
wooden packaging
Description

At present, the lightning arrester monitors have popularized in various large and small substations in China, and their own operating conditions will directly affect the safety of the power system. The lightning arrester's action and leakage current are usually monitored by the lightning arrester monitor. Due to poor sealing, the monitor may enter moisture or moisture during running, causing internal components to rust, or other causes of the monitor counter not functioning properly, and the leakage current indication is not allowed. Therefore, the "Procedures" stipulate that the lightninh arrester monitor should be inspected once a year. This instrument is our best choice.


Lightning Arrester Monitor Calibrator for Substation Safety Testing

​

Main features
The monitor count can be checked on-power/off-power
The accuracy of the monitor ammeter can be verified on-power/off-power
True RMS measurement, good stability
The inter-frequency output is strong in anti-interference ability under the online state
Standard sine wave output, the verification result is completely same
Built-in battery measurement, it's very convenient for on-site using

Lightning Arrester Monitor Calibrator for Substation Safety TestingLightning Arrester Monitor Calibrator for Substation Safety Testing

Product Parameters

Power supply built-in battery 4Ah 12V
Output frequency 55Hz
Output current 5mA/10mA (can customized)
Resolution 0.001mA
Current accuracy 0.5%±3 words
Inrush current 50A ~ 100A (instant)
Impact voltage DC 1000V
Action count 1 ~ 2s / times
Action number cyclical measurement
