Specifications
Brand Name :
XZH TEST
Model Number :
XHDP series
Certification :
CE, ISO
Place of Origin :
China
MOQ :
1 unit
Payment Terms :
T/T
Delivery Time :
5-8 work days
Packaging Details :
wooden packaging
Model NO. :
XHDP series
Test Mode :
Saved Test
Usage :
Network Cable Tester, HDMI Cable Tester, Audio Cable Tester, Coaxial Cable Tester, Digital Cable Tester
Test Region :
Forming Cable
Cable Type :
Shielded
Power :
Electricity
Customized :
Customized
Color :
Orange
Transport Package :
Wooden Box with Foam Inside
Specification :
350mm*280mm*170mm
Trademark :
XZH TEST
Origin :
China Xi′ an
HS Code :
8543201000
Supply Ability :
100 Pieces /Year
Customization :
Available
After-sales Service :
Warranty Certificate
Warranty :
1 Year
Description

AC DC Hipot Tester with Full Electronic Design and Protection Features

Product description
The product combines modern advanced digital variable frequency technology and micro computer control together, therefore, it can realize the full automatic voltage boost, step down, measurement and protection as well as the manual intervention in the process of automatic voltage boost. The full electronic design ensures the small size and light weight. The big LCD screen ensures the clear and visual display, and can display the output wave form. The printer outputs test reports. In addition, the product has features as follows:
AC DC Hipot Tester with Full Electronic Design and Protection FeaturesAC DC Hipot Tester with Full Electronic Design and Protection Features

Product description
In addition, the product has features as follows:
1.Data of current, voltage, wave form can be directly sampled at high voltage side, so the data is real and accurate.
2.Over voltage protection: If the output exceeds the set limit of voltage, the instrument will shut-down to protect itself; the actuation time is less than 20ms.
3.Over current protection: it is high-low voltage dual protection in the design, the accurate shut-down protection can be made according to the set value at high voltage side; If the current on low voltage side exceeds the rated current, the instrument will take shut-down protection, the actuation time are both less than 20ms.
4.A high voltage output protective resistor is provided in the voltage boost body in the design and this eliminates the need of additional protective resistor connected outside.

AC DC Hipot Tester with Full Electronic Design and Protection FeaturesAC DC Hipot Tester with Full Electronic Design and Protection FeaturesAC DC Hipot Tester with Full Electronic Design and Protection FeaturesAC DC Hipot Tester with Full Electronic Design and Protection Features
Model no. Rated Voltage Load Carrying
Capacity		 Power
Fuse Tube
XHDP-30 30kV
(Peak)		 0.1Hz,≤1.1µF 8A
0.05Hz,≤2.2µF
0.02Hz,≤5.5µF
XHDP-40 40kV(Peak) 0.1Hz,≤1.1µF 8A
0.05Hz,≤2.2µF
0.02Hz,≤5.5µF
XHDP-50 50kV
(Peak)		 0.1Hz,≤1.1µF 10A
0.05Hz,≤2.2µF
0.02Hz,≤5.5µF
XHDP-60 60kV(Peak) 0.1Hz,≤1.1µF 10A
0.05Hz,≤2.2µF
0.02Hz,≤5.5µF
XHDP-80 80kV
(Peak)		 0.1Hz,≤1.1µF 20A
0.05Hz,≤2.2µF
0.02Hz,≤5.5µF
XHDP-90 90kV
(Peak)		 0.1Hz,≤1.1µF 30A
0.05Hz,≤2.2µF
0.02Hz,≤5.5µF
