Black Sulfur Hexafluoride Quantitative Leak Detector with Accurate Measurement
Black Sulfur Hexafluoride Quantitative Leak Detector with Accurate Measurement
Black Sulfur Hexafluoride Quantitative Leak Detector with Accurate Measurement
Black Sulfur Hexafluoride Quantitative Leak Detector with Accurate Measurement
Black Sulfur Hexafluoride Quantitative Leak Detector with Accurate Measurement
Black Sulfur Hexafluoride Quantitative Leak Detector with Accurate Measurement
Black Sulfur Hexafluoride Quantitative Leak Detector with Accurate Measurement
Black Sulfur Hexafluoride Quantitative Leak Detector with Accurate Measurement
Black Sulfur Hexafluoride Quantitative Leak Detector with Accurate Measurement
Black Sulfur Hexafluoride Quantitative Leak Detector with Accurate Measurement
Specifications
Certification :
CE, ISO
Brand Name :
XZH TEST
Model Number :
XHJK306
Place of Origin :
Xi'an, Shaanxi, China
MOQ :
1 unit
Payment Terms :
T/T
Supply Ability :
1000pieces/Year
Delivery Time :
5-8 days
Packaging Details :
wooden case
Model NO. :
XHJK306
Power :
Electricity
Customized :
Customized
Color :
Black
Transport Package :
Wooden Box with Foam Inside
Specification :
229mm*65mm*65mm
HS Code :
9031809090
Customization :
Available
Warranty :
1 Year
Description

Product Description

XHJK306 is made according to the principle that the air which contains different SF6 concentrations to the gases which contain halogens are ionized differently under action of HF electromagnetic field. It can be used in sectors of electrical power, railway, manufacture of electrical equipment, chemical engineering, fire control research of nuclear physics to detect leak in equipment and vessel inflated with SF6 or gases containing halogens such as fluoric(F), chloride(CI), bromine(Br), iodine(I) as well as 1211, chloroform, Freon F11,12,13,F22 etc. Qualitative and quantitative detection can be quickly and accurately.

Product Parameters

Measurement Range 10-8-10-2(volume ratio)
Response Time EQ. or less than 3 seconds (10-4 gas)
Indication Mode LCD
Alarm Indications Audio
Setting Range of Alarm 10-8-10-2(volume ratio)
Speed of Vacuum Pump 0.5L/s
Length of Probe 4m
Continue Working Time one second
Operating Conditions (1) AC Power 220V±22V, 50Hz±2Hz
(2) Temperature 7ºC-40ºC
(3) Relative Humidity EQ. or less than 85%
Power 150W
