8x2 STN Blue Monochrome LCD Display 8x2 Character Display 5V ST7066 Module Replacement
8x2 STN Blue Monochrome LCD Display 8x2 Character Display 5V ST7066 Module Replacement
Specifications
Supply Ability :
10000 pieces
Color Gamut :
72 % of NTSC(Typ.)
Response Time :
6ms
Viewing Area :
116.2mm×87.1mm
MOQ :
500 pieces
Lumens Degrees :
1000cd/m²
Storage Temperature :
-30℃~80℃
Brand Name :
XXT
View Direction :
free/all
Delivery Time :
14-60 days
Payment Terms :
T/T
Display Mode :
Normally White, Transmissive
Display Color :
Monochrome Black and White
Interface :
RGB, SPI, MIPI, LVDS, or Parallel
Controller Ic :
SSD1316
Operating_Temperature :
-20°C to 70°C
Lcm Dimension :
34.60(H) X 47.80(V) X 1.90(T)
Price :
$1.38~2.32/pieces
Drive System :
a-Si TFT active matrix
Place of Origin :
GuangDong, China
Signal Interface :
LVDS
Model Number :
YMC0802SB-X01
Outline :
118.5×84.7×5.2 mm
Description
YMC0802SB-X01 8x2 Character LCD Module STN Blue Monochrome 5V with ST7066 Controller IC
Product Overview

The XXT YMC0802SB-X01 is a compact and reliable 8x2 Character LCD Module designed for industrial control systems, embedded devices, instrumentation, and smart electronic products. Featuring a high-contrast STN Blue Negative Display with a white LED backlight, this module provides clear character visibility and dependable performance in various operating environments.

Powered by the proven ST7066 controller IC, the module supports standard 5V operation and offers excellent compatibility with microcontrollers, embedded platforms, and industrial control systems.

Its durable PCB and metal frame construction ensures stable operation and long service life, making it an ideal display solution for professional electronic applications.

Key Features
  • 8 Characters × 2 Lines display format
  • STN Blue Negative transmissive display
  • White characters on blue background
  • ST7066 LCD controller IC
  • Standard 5V operating voltage
  • White LED backlight for improved visibility
  • 14-pin interface for easy integration
  • Wide operating temperature range
  • Compact PCB and metal frame construction
  • Low power consumption design
  • Suitable for embedded and industrial applications
  • Reliable long-term operation
Technical Specifications
Parameter Specification
Model Number YMC0802SB-X01
Display Type STN Blue Negative LCD
Display Format 8 Characters × 2 Lines
Controller IC ST7066
Operating Voltage 5.0V DC
Driving Method 1/16 Duty, 1/5 Bias
Viewing Direction 6 O'Clock
Backlight Type White LED
Backlight Current 20mA
Interface 14-Pin Parallel Interface
Structure PCB + Metal Frame
Operating Temperature -20°C to +70°C
Storage Temperature -30°C to +80°C
Display Mode White Characters on Blue Background
Display Advantages
High Contrast STN Display

The STN blue negative display provides excellent character visibility with bright white characters against a deep blue background, ensuring clear readability in both indoor and low-light environments.

Stable Controller Performance

The integrated ST7066 controller offers dependable display operation and excellent compatibility with a wide range of embedded control platforms.

Energy-Efficient Backlight

The white LED backlight provides uniform illumination while maintaining low power consumption, making it suitable for battery-powered and portable devices.

Interface Configuration

The module features a standard 14-pin interface for straightforward hardware integration.

Pin Functions
Pin Function
1 GND
2 VDD
3 VO
4 RS
5 RW
6 E
7-14 DB0 ~ DB7

This standardized interface simplifies system development and supports seamless integration with most embedded platforms.

Typical Applications
Industrial Automation
  • Industrial control panels
  • Process monitoring equipment
  • Machine operation interfaces
  • PLC display systems
Measurement & Instrumentation
  • Digital meters
  • Testing equipment
  • Data acquisition devices
  • Calibration instruments
Embedded Electronics
  • Embedded controller displays
  • IoT terminals
  • Development boards
  • Smart sensor interfaces
Consumer Electronics
  • Portable electronic devices
  • Handheld instruments
  • Smart appliance displays
  • Battery-powered equipment
Automotive Electronics
  • Auxiliary display systems
  • Vehicle monitoring devices
  • Control interfaces
  • Information display modules
Medical Equipment
  • Portable diagnostic devices
  • Monitoring instruments
  • Healthcare electronics
  • Laboratory equipment
Mechanical Design Benefits

The module combines a robust PCB structure with a reinforced metal frame, providing:

  • Improved structural stability
  • Enhanced vibration resistance
  • Reliable long-term performance
  • Easy installation and assembly
  • Consistent display quality

This construction makes the module suitable for demanding industrial and commercial environments.

Quality Assurance

Each module undergoes comprehensive inspection and functional testing before shipment, including:

  • Display performance verification
  • Backlight inspection
  • Interface testing
  • Visual appearance inspection
  • Reliability validation

This process helps ensure consistent product quality and dependable field performance.

Customization Services

XXT supports flexible OEM and ODM customization services, including:

  • Display color options
  • Backlight customization
  • Interface modification
  • Connector customization
  • Mechanical structure adjustment
  • Custom labeling and branding
  • Packaging solutions
Packaging & Logistics
Sample Orders

Available for engineering evaluation and prototype development.

Lead Time

Standard lead time is typically 7 working days after order confirmation.

Minimum Order Quantity

Flexible MOQ available, including single-unit sample orders.

Shipping Options
  • DHL
  • FedEx
  • UPS
  • EMS
  • Air Freight
  • Sea Freight

Worldwide shipping services are available.

Why Choose XXT
  • Professional LCD display manufacturer
  • Extensive experience in industrial display solutions
  • Stable production and supply capability
  • Consistent quality control process
  • Responsive technical support
  • Flexible customization services
  • Global delivery support

The XXT YMC0802SB-X01 8x2 Character LCD Module provides a dependable monochrome display solution for industrial equipment, embedded electronics, instrumentation, and smart device applications requiring compact size, low power consumption, and reliable performance.
