Specifications
Brand Name :
XCMG
Model Number :
GR3505 350Hp
Certification :
EPA/CE
Place of Origin :
China
MOQ :
1 unit
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
100 unit
Delivery Time :
5-8 work days
Packaging Details :
frame
Applicable Industries :
Construction works
Showroom Location :
Philippines, Peru, Algeria, Bangladesh, Uzbekistan
Video outgoing-inspection :
Provided
Machinery Test ReportC :
Provided
Marketing Type :
New Product 2020
Warranty of core components :
1 Year
Description

(1)Warranty:Every product issued shall enjoy a one-year/2000 working hour warranty period, during which we will repair or replace the defective parts free of charge if material or process defects occur and spare parts are in normal working condition.

(2)Spare parts:CANMAX is dedicated to provide our clients with genuine spare parts with the highest quality,exact fitness and appropriate function.with our global distributor network,you are guaranteed with fast deliveries and services, wherever you are,please submit your spare parts request to us,and list products name ,description of required parts.we guarantee that your request will be handled quickly and appropriately.

(3)Installation & Maintenance:CANMAX is able to provide with the overall installation of complicated machinery,allowing you to start the normal operation of construction machinery solutions.After installation,we will make inspection of the whole machine,operate equipment,and provide you with testing data reports of installation and operation.

(4)Training:CANMAX offer perfect facilities and comfortable environment and can provide training services to different users. The training sessions include product training, operation training, maintenance know-how, technical know-how training, standards, laws and regulations training and other training, all of which are tailored to fulfill your individual needs. Training programs can be conducted in our factory field, or at the client's site.

(5)Technical Advice: CANMAX can also help customers to coordinate with trained service personnel and provide you with detailed and extensive knowledge. Through our technical advice, your machine life can be significantly extended and sustained high capacity

Description Unit Parameter value
Engine model QSM 11
Rated power/speed kW/rpm 261/2100
Overall dimension (standard) 11250X3180X3820
Total weight (standard) kg 30000
Tire specification 23.5R25
Ground clearance (front axle) mm 500
Tread mm 2580
Space of front and rear axles mm 7200
Space of middle and rear wheels mm 1960
Forward velocity km/h 5/8.5/13/20/30/45
Reverse speed km/h 5/13/30
Tractive effort f=0.75 kN 165
Maximum gradeability % 25
Tire inflation pressure kPa 320
Working system pressure MPa 25
Maximum steering angle of front wheel ±45°
Maximum slant angle of front wheel ±17°
Maximum oscillating angle of front axle ±15°
Maximum oscillating angle of equilibrium box Front15°,Rear15°
Maximum steering angle of frame ±22°
Minimum turning radius m 8.9
Scrape knife Maximum lift height mm 450
Maximum cutting depth mm 500
Maximum tilt angle 65°
Cutting angle 28°—70°
Angle of revolution 360°
Length & chord height mm 4877x787
Coolant L 50
Fuel tank L 550
Engine L 37
Transmission L 38
Hydraulic oil L 310
Drive axle L 106
Balancing box L 186
