Car bomb detector Under Vehicle Inspection System SPV-3300 High Resolution UVSS/UVIS for airport use

SECUPLUS Under vehicle surveillance system mainly adopt to inspect the beneath part of a variety of vehicles. It can quickly and accurately identify threats/ contraband/ smuggling of persons hiding at the bottom. UVSS greatly improved vehicle safety inspection speed and accuracy, reduce investment in human resources.

Highlight:

Special air-drying circulation system
With intelligent alarm
Weather proof scanning unit(IP 68)
Anti-fog function
To connect anti-collision system, barrier,etc,
To compatibly packing management solution

Features:

1. Multi entrance management model, management, and statistics of entering and exiting vehicles
2. Auto digital line scan, high-resolution undercarriage imaging.
3. High automation, easy to be used
4. Applicable to variety of vehicles, wide vision.
5. Test will be completed during the vehicle maneuvers
6. without stopping, adapted to different speed.
7. Undercarriage image can be stored, retrieved, searched or compared with other images.
8. Avariety of image processing methods: enlarge, stretching and cutting.
9. (Optional)ALPR-Automatic License Plate Recognition and RFID technology. associative storage of various
10. vehicle information and undercarriage images.

Embedded Screening Part:

• Illumination: LED
• Power Supply: 24VDC,150W
• Size: 1200mm x 350mm
• Operating Temperature Range: -20 degree to +70 degree

Controller:

● Input: 2 channels induction coil
● Output: 1 Channel switch type 12VDC
● Communication port: RS485, Ethernet(Optional)
● Operating Temperature: -10℃ to 55℃

System Host:

• E3400@2.6GHz 2.59 GHz
• Graphics:512M
• Hard Disk: SATA2 Hard Disk 500G
• Dual LAN (At least one Intel Gigabit)
• USB2.0 (Up to 2 pieces)
• Monitor: 22 inch LCD, resolution up to 1920*1080
• Scene Video Record: 4 channel, Compression algorithm of scene video: H264
