The ZCN Series Zirconia Ceramic High Temperature Nozzle is purpose-built for thermal spray, plasma welding, and high-temperature industrial processes. Fabricated from high-purity magnesia-stabilized zirconia (MSZ) or yttria-stabilized zirconia (YSZ), these nozzles withstand continuous operating temperatures up to 1600°C while maintaining excellent dimensional stability and thermal shock resistance.

Key Features

• Ultra-High Temperature Rating: Continuous service up to 1600°C with exceptional thermal shock resistance, surviving rapid ΔT >800°C without cracking
• Precision CNC Machined: Custom-fabricated to tight tolerances with consistent bore geometry for stable plasma arc and spray pattern control
• Low Thermal Conductivity: Zirconia ceramic thermal conductivity of 2.0-2.5 W/m·K minimizes heat loss and improves process energy efficiency
• Excellent Erosion Resistance: Dense sintered microstructure resists particle erosion in plasma spray and powder injection applications
• Chemical Inertness: Non-reactive with molten metals, slags, and reactive gases; ideal for metallurgical and chemical process nozzles
• Custom Configurations: Available in various bore sizes, lengths, and mounting geometries to fit major OEM plasma equipment

Technical Specifications

Applications

Plasma spray guns, plasma welding torches, HVOF thermal spray systems, combustion burners, molten metal pouring nozzles, furnace components, glass fiber drawing nozzles, and high-temperature gas flow control. Compatible with Metco, F4, SG-100, and other major plasma gun platforms.

Custom Manufacturing

We manufacture custom nozzles per drawing or sample. Bore diameter from 0.5mm to 20mm, outer diameter up to 100mm, and length up to 200mm. Special coatings and multi-material assemblies available upon request. Contact our team to discuss your specific nozzle requirements.
