5000VA Rated Power Toroidal Transformer for UPS UL/CE/RoHS/CQC
5000VA Rated Power Toroidal Transformer for UPS UL/CE/RoHS/CQC
5000VA Rated Power Toroidal Transformer for UPS UL/CE/RoHS/CQC
5000VA Rated Power Toroidal Transformer for UPS UL/CE/RoHS/CQC
5000VA Rated Power Toroidal Transformer for UPS UL/CE/RoHS/CQC
5000VA Rated Power Toroidal Transformer for UPS UL/CE/RoHS/CQC
5000VA Rated Power Toroidal Transformer for UPS UL/CE/RoHS/CQC
5000VA Rated Power Toroidal Transformer for UPS UL/CE/RoHS/CQC
5000VA Rated Power Toroidal Transformer for UPS UL/CE/RoHS/CQC
5000VA Rated Power Toroidal Transformer for UPS UL/CE/RoHS/CQC
5000VA Rated Power Toroidal Transformer for UPS UL/CE/RoHS/CQC
5000VA Rated Power Toroidal Transformer for UPS UL/CE/RoHS/CQC
Specifications
Brand Name :
IKP
Model Number :
Toroidal Transformer
Certification :
CE/UL/REACH/ROHS
Place of Origin :
CHINA
MOQ :
1000
Price :
3.00-20.00
Payment Terms :
L/C, T/T
Supply Ability :
100,000/week
Delivery Time :
10-15 days
Packaging Details :
Carton
Description

Specifications:

• Power range:500VA to 10000VA

• Phase: Single

• Input / Output: Customized

• Insulation Class: UL class B, F, H, N (optional)

• Isolation: 4KV (Hi-pot)

• Easy to change diameter and height of the core

• Customized specifications are welcome

Rated Power

(VA)

Outside Dimension

D*H(mm)

Weight

(kg)

Temp. Rise

(℃)

 Approval
500 145*65 5.5 52 UL/CE/RoHS/CQC
1000 175*85 8.5 54 UL/CE/RoHS/CQC
2000 210*90 14.7 55 UL/CE/RoHS/CQC
2500 210*100 16.7 56 UL/CE/RoHS/CQC
3000 215*105 17.7 57 UL/CE/RoHS/CQC
3500 230*115 21.8 58 UL/CE/RoHS/CQC
5000 290*115 30.0 59 UL/CE/RoHS/CQC
7000 330*115 35.0 62 UL/CE/RoHS/CQC
10000 360*115 45.0 65 UL/CE/RoHS/CQC


◆We can design and manufacture customized part with specific requirement
