ACSR 240/30 Overhead Aluminum Conductor Seel Reinforced AL 24/3.60 ST 7/2.40 GB/T1179--2017
ACSR 240/30 Overhead Aluminum Conductor Seel Reinforced AL 24/3.60 ST 7/2.40 GB/T1179--2017
ACSR 240/30 Overhead Aluminum Conductor Seel Reinforced AL 24/3.60 ST 7/2.40 GB/T1179--2017
ACSR 240/30 Overhead Aluminum Conductor Seel Reinforced AL 24/3.60 ST 7/2.40 GB/T1179--2017
ACSR 240/30 Overhead Aluminum Conductor Seel Reinforced AL 24/3.60 ST 7/2.40 GB/T1179--2017
ACSR 240/30 Overhead Aluminum Conductor Seel Reinforced AL 24/3.60 ST 7/2.40 GB/T1179--2017
Specifications
Brand Name :
Zhenglan Cable
Model Number :
ACSR 240/30
Certification :
3C，ISO 9001:2015，ISO 14001:2005
Place of Origin :
Henan, China
MOQ :
5000meters
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
15tons/day
Delivery Time :
15-30 days
Packaging Details :
Fully wooden drum, steel wooden drum, fully steel drum or customized
Commodity item :
ACSR 240/30
AWG :
AL 24/3.60 ST 7/2.40
Number of Conductors :
1
Conductor Material :
Bare Aluminum, galvanized steel
Insulation :
non
Application :
overhead line use
Description

Construction

Aluminum Conductors, Steel-Reinforced (ACSR) is a concentric-lay-stranded conductor consisting of galvanized steel central core with one or more layers of hard drawn stranded aluminum wires laid helically over the steel core. Steel core wires are protected from corrosion by galvanization.

Additional corrosion protection is available through the application of grease.

Nominal Cross-section(AL/ST) Aluminum Galvanized steel Approx.Overall diameter Approx.Overall weight Maximum DC resistance at 20oC Minimum breaking load Current carrying Capacity(*)
mm2 No. x mm No. x mm mm kg/km Ω/km kN A
240/30 24 x 3.60 7 x 2.40 21.60 920 0.118 75.19 661

ACSR 240/30 Overhead Aluminum Conductor Seel Reinforced AL 24/3.60 ST 7/2.40 GB/T1179--2017

ACSR 240/30 Overhead Aluminum Conductor Seel Reinforced AL 24/3.60 ST 7/2.40 GB/T1179--2017

ACSR 240/30 Overhead Aluminum Conductor Seel Reinforced AL 24/3.60 ST 7/2.40 GB/T1179--2017

Why you choose us?

  • OEM/ODM services provided;
  • Products comply with GB, IEC, BS, ASTM, DIN, VDE and JIS standards; Customer standard requirments Accepted;
  • Certified to ISO 9001:2015, ISO 14001:2015 and OHSAS 18001:2007;
  • Registered capital of $30 million and factory covers an area of 60,000㎡;
  • Advanced test equipment and procedures, 100% inspection before factory;
  • Enough stocks and the higest efficient shipping time guarranteed;
  • Professional pre-sales and after-sales services provided.
