All Aluminum Alloy Conductor ASTM B399 AAAC Cable Bare Aluminum Alloy 6201 Wires
All Aluminum Alloy Conductor ASTM B399 AAAC Cable Bare Aluminum Alloy 6201 Wires
All Aluminum Alloy Conductor ASTM B399 AAAC Cable Bare Aluminum Alloy 6201 Wires
All Aluminum Alloy Conductor ASTM B399 AAAC Cable Bare Aluminum Alloy 6201 Wires
All Aluminum Alloy Conductor ASTM B399 AAAC Cable Bare Aluminum Alloy 6201 Wires
All Aluminum Alloy Conductor ASTM B399 AAAC Cable Bare Aluminum Alloy 6201 Wires
Specifications
Brand Name :
Zhenglan Cable
Model Number :
All Aluminum Alloy Conductor ASTM B399 AAAC cable Bare Aluminum Alloy 6201 Wires
Certification :
3C，ISO 9001:2015，ISO 14001:2005
Place of Origin :
Henan, China
MOQ :
3000meter
Price :
Negotiable
Payment Terms :
L/C, T/T,
Supply Ability :
100KM/Month
Delivery Time :
15-30 days
Packaging Details :
Fully wooden drum, steel wooden drum, fully steel drum or customized
Material :
Aluminum Alloy
Size :
70mm2
Grease :
Optional
Standard: :
IEC 60189/IEC60888
Insulated :
No
Certificated :
3C，ISO 9001:2015，ISO 14001:2005, CE
Shape :
Round
Temperature Range :
-40~+90℃
Description

All Aluminum Alloy Conductor ASTM B399 AAAC cable Bare Aluminum Alloy 6201 Wires

Application:

It's mainly used for overhead lines , in transmission and distribution electrical networks, having relatively long spans. They are also used a messenger to support overhead electrical cables.

Electrical properties:
Density@20ºC 2.70 kg/dm
Temperature coefficient @20°C 0.00360 (°C)
Resistivity @20°C 0.0326 Ohms mm²/m
Linear change rate of linear expansion coefficient 23 x10-6(°C)

Technical data sheet:

Cross
Sectional
Area		 Number
and
Nominal
Diameter
of Wires		 Max. DC.
resistance
at
20ÜC		 Rated
strength		 Approx.
overall
diameter		 Approx.
Weight		 Current
carrying
capacity
mm2 No x Ø (mm) Ω/.m KN mm Kg/Km Amp
35 7X2.5 0.9572 10.14 7.5 93.8 170
50 7x3 0.6647 14.6 9 135.1 210
50 19X1.8 0.6841 14.26 9 132.7 210
70 19X2.1 0.5026 19.41 10.5 180.7 255

Pictures:

All Aluminum Alloy Conductor ASTM B399 AAAC Cable Bare Aluminum Alloy 6201 WiresAll Aluminum Alloy Conductor ASTM B399 AAAC Cable Bare Aluminum Alloy 6201 WiresAll Aluminum Alloy Conductor ASTM B399 AAAC Cable Bare Aluminum Alloy 6201 Wires

Why you choose us?

  • Products comply with GB, IEC, BS, ASTM, DIN, VDE and JIS standards; Customer standard requirments Accepted;
  • Certified to ISO 9001:2015, ISO 14001:2015 and OHSAS 18001:2007;
  • Registered capital of $30 million and factory covers an area of 60,000㎡;
  • Advanced test equipment and procedures, 100% inspection before factory;
  • Enough stocks and the higest efficient shipping time guarranteed;

FAQ

  • Is your company a factory or a trade company? --- Factory, more than 20 years in China
  • How long can I expect to get the sample?---After you pay the freight charge and send us confirmed files, the samples will be ready for delivery in 3-7 days. The samples will be sent to you via express and arrive in 3~7 days. You can use your own express account or prepay us if you do not have an account.
  • What are your payment terms?---We normally accept T/T 30% deposit, 70% balance before delivery as the main payment terms, and other payment can also be negotiated. Trade assurance on is also available.
  • What’s the delivery time?---Sample order needs 3~5 days. Formal order depends on the quantity. Usually it needs 7-30 days after get your payment.
  • What is your MOQ?---depends on the cable type you need.
