Specifications
Place of Origin :
Henan, China
Brand Name :
HOLD-ONE
Model Number :
YH/YHF
MOQ :
500-49999 Meters
Price :
$15.00
Insulation Material :
Rubber
Type :
Low Voltage
Application :
Industrial
Conductor Material :
Copper
Jacket :
Rubber
Product name :
95mm2 Welding Machine Cable
Standard :
GB5013-2008
Certificate :
ISO9001
Rated voltage :
Not more than 200v
Core :
1 Core
Layer :
Single ,Double
Color :
Customized
Sample :
Provided
Payment Terms :
FOB/CIF/CFR
Package :
Customized as the customer's demands
Selling Units :
Single item
Single package size  :
85X35X35 cm
Single gross weight :
6.000 kg
Package Type :
Small Drum or Wheel or others
Description

Black Rubber Sheath 200v 95mm2 Flexible Welding Cable

Product Description

1.Usages:

This product is suitable for the voltage to the ground not more than 200v and its pulsating direct current peak value 400v welding machine electric welding pliers and so on.

2.Guide & Selection :

Welding cable are generally used for connecting the electrode to the welding machine .Howervr welding cable can be used for a varity of other applications that require exteremely flexible and durable cables with high ampacities.

3.What is Welding Cable?

Welding cable is designed for use in electric arc-welding machines to power an electrode ,a specially designed metal rod,that conducts a charge.The charge carried by the electrode is needed to produce an electric arc,the heat source,between the electrode and the metals or other materials ,being welded.

4.Model,Names and Work in Temperature(see table 1):

Model

Name

Working Temperature of core

60245IEC81(YH)

Natural rubber sheath for welding machine cable

65℃

60245IEC82(YHF)

Chloroprene rubber or other elastomer sheath welding machine cable

65℃

5.Specifications,Size,Weight and Technological Data(see table 2):

Conductive Nominal Section

Conductive core

Thickness of section sheath

Average outer diameter(mm)

20℃conductor resistance

Reference weight(kg/km)

mm2

Number diameter of core(mm)

mm

Min

Max

≤(Ω/km)

YH

YHF

16

513/0.20

2.0

9.2

11.5

1.16

218.9

230.44

25

798/0.20

2.0

10.5

13.0

0.758

316.6

331.15

35

1121/0.20

2.0

11.5

14.5

0.536

426

439.87

50

1596/0.20

2.2

13.5

17.0

0.379

592.47

610.55

70

2214/0.20

2.4

15.0

19.5

0.268

790

817.52

95

2997/0.20

2.6

17.0

22.0

0.198

1066.17

1102.97

6.Delivery Requirements:

If cable packed in circle,it should be 100m in length.If packed in bundle,it should be no less than 100m.If short distance,no less than 20m.If mutual agreement is made,everything will be done according to agreement.

7.Welding Cable Types:

A.Single layer

Black Rubber Sheath 200v 95mm2 Flexible Welding Cable

B.Double Layer

Black Rubber Sheath 200v 95mm2 Flexible Welding Cable8.Related Product Images:

Black Rubber Sheath 200v 95mm2 Flexible Welding Cable
