Specifications
Model Number :
Cyrillic 2004A 3.3V
Color :
Yellow Green Film
Origin :
Mainland China
Outline Dimension :
98x60x13.1mm
Controller :
ST7066U
View Size :
77×25.2mm
Type :
COB
Display Mode :
2004
Resolution :
20*04
Hign-concerned Chemical :
None
is_customized :
Yes
Description

Cyrillic 2004A 3.3V

High-quality Cyrillic 2004A 3.3V display module designed for various industrial and commercial applications. This reliable display ensures clear and efficient communication of information.

Key Benefits:

  • Clear and crisp display
  • Low voltage operation (3.3V)
  • Durable and reliable
  • Easy to integrate

Target Industries and Applications:

Suitable for use in industrial control panels, instrumentation, and other embedded systems requiring a reliable display.

FOB Price 3.13 USD / piece

Technical Specifications

Attribute Value
Hign-concerned Chemical None
Display Mode 2004
Resolution 20*04
is_customized Yes
Model Number Cyrillic 2004A 3.3V
Type COB
Origin Mainland China
Outline Dimension 98x60x13.1mm
View Size 77×25.2mm
Controller ST7066U


Cyrillic Yellow Green Film 2004A 3.3V Liquid Crystal Display Spot Module ST7066U Font Screen

Cyrillic Yellow Green Film 2004A 3.3V Liquid Crystal Display Spot Module ST7066U Font Screen

Cyrillic Yellow Green Film 2004A 3.3V Liquid Crystal Display Spot Module ST7066U Font Screen

Cyrillic Yellow Green Film 2004A 3.3V Liquid Crystal Display Spot Module ST7066U Font Screen

Cyrillic Yellow Green Film 2004A 3.3V Liquid Crystal Display Spot Module ST7066U Font Screen

Cyrillic Yellow Green Film 2004A 3.3V Liquid Crystal Display Spot Module ST7066U Font Screen

Cyrillic Yellow Green Film 2004A 3.3V Liquid Crystal Display Spot Module ST7066U Font Screen

1. LCD size: The maximum overall size or viewing area size, which size should be specified when providing it

2. LCD thickness: The thickness of conventional single glass is divided into 0.55mm,0.7mm, and 1.1mm

3. Display mode: Generally, there are five display modes: TN, HTN, STN, FSTN, and VA. Additionally, it is necessary to provide positive or negative display.

4. Generally, the VA screen is used for negative display

5. Polarizer type: fully transparent (with or without backlight), semi transparent (with or without backlight), reflective (without backlight)

6. Working temperature: 0 °C~+50 °C, -10 °C~+60 °C, -20 °C~+70 °C, -30 °C~80 °C,-40°C~+90°C

7. Connection method: metal pins, zebra stripes, FPC, etc

8. Working voltage: determined according to customer requirements

9. Drive method: commonly used 1/4DUTY 1/3BAIS according to customer requirements

10. Driver IC: The commonly used IC for segment code screens is usually 1621 or 1622
