Blue Film White Letters 2002A High Brightness LCD Screen Audio Amplifier Display Screen Factory Outlet

Specifications

Hign-concerned Chemical :

None

Controller :

ST7066U

is_customized :

Yes

Color :

Blue Film

Outline Dimension :

116x37x11.5mm

Type :

COB

View Size :

83×18.6mm

Display Mode :

2002

Model Number :

2002A

Origin :

Mainland China

Resolution :

20*02

Description

2002A

The 2002A is a versatile display module designed for a wide range of industrial and commercial applications. Its robust construction and clear display make it an ideal choice for demanding environments.

Key Benefits:

Clear and easily readable display
Durable construction for industrial use
Customizable options available
Compact design for easy integration
Reliable performance

Target Industries & Applications:

Suitable for use in industrial control panels, instrumentation, and other embedded systems.

Product Attributes

FOB Unit: piece

Product MOQ: 0

FOB Price: 2.48

Packaging & Delivery: Tax excluded, add at checkout if applicable.

Technical Specifications

Attribute	Value
Hign-concerned Chemical	None
Display Mode	2002
Resolution	20*02
Is Customized	Yes
Model Number	2002A
Type	COB
Origin	Mainland China
Outline Dimension	116x37x11.5mm
View Size	83×18.6mm
Controller	ST7066U

Blue Film White Letters 2002A High Brightness LCD Screen Audio Amplifier Display Screen Factory Outlet

1. LCD size: The maximum overall size or viewing area size, which size should be specified when providing it

2. LCD thickness: The thickness of conventional single glass is divided into 0.55mm,0.7mm, and 1.1mm

3. Display mode: Generally, there are five display modes: TN, HTN, STN, FSTN, and VA. Additionally, it is necessary to provide positive or negative display.

4. Generally, the VA screen is used for negative display

5. Polarizer type: fully transparent (with or without backlight), semi transparent (with or without backlight), reflective (without backlight)

6. Working temperature: 0 °C~+50 °C, -10 °C~+60 °C, -20 °C~+70 °C, -30 °C~80 °C,-40°C~+90°C

7. Connection method: metal pins, zebra stripes, FPC, etc

8. Working voltage: determined according to customer requirements

9. Drive method: commonly used 1/4DUTY 1/3BAIS according to customer requirements

10. Driver IC: The commonly used IC for segment code screens is usually 1621 or 1622
