Specifications
Hign-concerned Chemical :
None
is_customized :
Yes
Origin :
Mainland China
Resolution :
122*32
Model Number :
Owen 12232B1
Display Mode :
12232
Type :
COB
View Size :
60x18mm
Controller :
SBN1661G
Color :
Yellow Green Film
Outline Dimension :
84.1x44x12.9mm
Description

Owen 12232B1

The Owen 12232B1 is a reliable and versatile display module designed for a variety of industrial and commercial applications. Its compact design and clear display make it an excellent choice for integration into your products.

Key Benefits:

  • Clear and readable display
  • Compact and easy to integrate
  • Durable and long-lasting
  • Suitable for various applications
  • Customizable options available

Target Industries: Industrial automation, consumer electronics, medical devices, and more.

Applications: Control panels, instrumentation, handheld devices, and embedded systems.

Product Attributes

FOB Unit: piece
Product MOQ: Unknown
FOB Price: $28.0
Packaging & Delivery: Unknown

Technical Specifications

Attribute Value
Hign-concerned Chemical None
Display Mode 12232
Resolution 122*32
Is Customized Yes
Model Number Owen 12232B1
Type COB
Origin Mainland China
Outline Dimension 84.1x44x12.9mm
View Size 60x18mm
Controller SBN1661G


Yellow Green Film 12232B1 LCD Screen High Brightness Screen LCD Screen Display Module 18PIN Standard Interface

Yellow Green Film 12232B1 LCD Screen High Brightness Screen LCD Screen Display Module 18PIN Standard Interface

Yellow Green Film 12232B1 LCD Screen High Brightness Screen LCD Screen Display Module 18PIN Standard Interface

Yellow Green Film 12232B1 LCD Screen High Brightness Screen LCD Screen Display Module 18PIN Standard Interface

Yellow Green Film 12232B1 LCD Screen High Brightness Screen LCD Screen Display Module 18PIN Standard Interface

Yellow Green Film 12232B1 LCD Screen High Brightness Screen LCD Screen Display Module 18PIN Standard Interface

1. LCD size: The maximum overall size or viewing area size, which size should be specified when providing it

2. LCD thickness: The thickness of conventional single glass is divided into 0.55mm,0.7mm, and 1.1mm

3. Display mode: Generally, there are five display modes: TN, HTN, STN, FSTN, and VA. Additionally, it is necessary to provide positive or negative display.

4. Generally, the VA screen is used for negative display

5. Polarizer type: fully transparent (with or without backlight), semi transparent (with or without backlight), reflective (without backlight)

6. Working temperature: 0 °C~+50 °C, -10 °C~+60 °C, -20 °C~+70 °C, -30 °C~80 °C,-40°C~+90°C

7. Connection method: metal pins, zebra stripes, FPC, etc

8. Working voltage: determined according to customer requirements

9. Drive method: commonly used 1/4DUTY 1/3BAIS according to customer requirements

10. Driver IC: The commonly used IC for segment code screens is usually 1621 or 1622
