High Temperature Resistant Anti-static Vibration Tuning Fork Water Level Switch
High Temperature Resistant Anti-static Vibration Tuning Fork Water Level Switch
High Temperature Resistant Anti-static Vibration Tuning Fork Water Level Switch
High Temperature Resistant Anti-static Vibration Tuning Fork Water Level Switch
High Temperature Resistant Anti-static Vibration Tuning Fork Water Level Switch
High Temperature Resistant Anti-static Vibration Tuning Fork Water Level Switch
High Temperature Resistant Anti-static Vibration Tuning Fork Water Level Switch
High Temperature Resistant Anti-static Vibration Tuning Fork Water Level Switch
High Temperature Resistant Anti-static Vibration Tuning Fork Water Level Switch
High Temperature Resistant Anti-static Vibration Tuning Fork Water Level Switch
Specifications
Model Number :
LS-500
Place of Origin :
Guangdong, China
Brand Name :
BAIRUI
MOQ :
2 pieces
Price :
Negotiable
Mounting Type :
Threaded installation
Description :
ultrasonic sensor
Type :
Ultrasonic Sensor
Usage :
Liquid level measurement
Theory :
Vibration occurs at the mechanical resonance frequ
Output :
PNP/NPN
Amplifier Type :
Standard
Voltage - Supply :
24v DC/220V AC
Detection Distance :
5000mm
Material :
Stainless steel
Description
LS-500 High Temperature Resistant Anti-static Vibration Tuning Fork Water Level Switch
High Temperature Resistant Anti-static Vibration Tuning Fork Water Level Switch High Temperature Resistant Anti-static Vibration Tuning Fork Water Level Switch High Temperature Resistant Anti-static Vibration Tuning Fork Water Level Switch High Temperature Resistant Anti-static Vibration Tuning Fork Water Level Switch High Temperature Resistant Anti-static Vibration Tuning Fork Water Level Switch High Temperature Resistant Anti-static Vibration Tuning Fork Water Level Switch High Temperature Resistant Anti-static Vibration Tuning Fork Water Level Switch High Temperature Resistant Anti-static Vibration Tuning Fork Water Level Switch
The LS-500 tuning fork level switch is a simple, reliable and efficient point-type level control device. It determines whether the liquid level exists by detecting the changes in the vibration state of the fork teeth and is widely used in pump control, alarm and protection functions in various industrial processes. When making a choice, just ensure that its material and specifications match your process medium and conditions.
Technical Specifications
Power Supply 19…60VDC 19…250VAC 50/60Hz
Switching Time In the medium 2 seconds, Empty: 3 seconds
Environment Temperature -40…+70°C
Shelf Temperature -40…+85°C
Medium Temperature -40…+150°C
Working Pressure -1…+40bar
Medium Type Powder and particle ≤10mm,density>0.1g/cm³ Liquid,Viscosity ≤10000mm²/s, density >0.7g/cm³
Process Connection M20×1.5,G1-1/2",customization
Electric Connection M12×P1.0 Connector
Shell Material SS304
Fork Material SS304/SS316
Output Relay, AC250V/4A, DC60V/4A NPN, 400mA PNP, 400mA
Power Consumption DC<3W, AC <15W
Packing & Delivery
High Temperature Resistant Anti-static Vibration Tuning Fork Water Level Switch
About Bairui Electric Technology Co., Ltd.
Bairui Electric Technology Co., Ltd. was established in January 2013. We are a professional company focused on sensor product research and development, design, production, and trade. With more than ten years of technology accumulation, we follow the business philosophy of technology first and service first, to provide customers with complete mature application solutions. The industries we serve include pharmaceutical, aerospace, chemical, electronics and other sectors. In foreign trade, we have rich experience in dealing with all aspects of international business. The company promises: "reasonable price, short production time, satisfactory after-sales service". We hope to cooperate with more customers for common development and mutual benefit. Potential buyers are welcome to contact us.
