Specifications
Place of Origin :
China
Brand Name :
HUARAY
Model Number :
HR-1029
Certification :
FCC,CE,RoHS
Packaging Details :
Inner Staticproof Bag, External Cardboard Box
Delivery Time :
1~3 days
Payment Terms :
T/T Western Union, Moneygram, Paypal
Supply Ability :
500,000pcs/year
MOQ :
2/pcs
Price :
Negotiable
Description

Description:

HR-1029 the high speed data radio is designed to be low cost and high performance radio modem. The new design makes the modem more flexible for different application in various configurations. Basically, this type of modem is SMART enough to be customized to best meet end user’s requirements. Users don’t have to pay the features that never be used in their projects. The following lists its general functionalities of this series.

APPLICATION:

* AMR Automatic Meter Reading

* Wireless alarm and security systems

* Building automation, security, wireless monitoring and control of room equipment, Access Control System;

* Wireless data transmission, automatic data collection system;

* Low power telemetry

* 433 / 868 and 915 MHz ISM/SRD band systems

* Data radio can be used for Wireless conference voting system;

* Mapping;

* Radio modem can be used for Sports training & competition;

* Wireless dishes ordering;

* Wireless POS, PDA wireless smart terminal;

* RF modem can be used for Electronic bus station and intelligent traffic;

* RF transmitter Wireless electronic display screen and queuing machine;

* Wireless telemetry Charging for parking, parking lot;

* Wireless modem Automobile inspection and four-wheel orientation;

* Wireless sensor Industrial wireless remote control and air conditioning remote controller;

* Data communication used for railway, oil field, dock and army.

* LED display in thruway and public places

* Wireless RS232/RS485 conversion/connector;

* Point to multi-point wireless network, wireless on-the-spot bus and automatic data collection system;

Technical specification of HR-1029:

PERFORMANCE

Power Output:

≤2W (customized)

RF Line-of-sight Range:

5Km@9600bps,7Km@1200bps

RF Effective Rate:

1200~38400bps optional, 57600bps customized

Receiver Sensitivity:

-123dBm@1200bps, -118dBm@9600bps

NETWORKING

Networking Topology:

Point-to-point, point-to-multipoint

POWER

Supply Voltage:

5V DC(customized according requirement)

Transmitting Current:

<;1.5A

Receiving Current:

<;30mA (TTL connect)

Sleeping Current:

<;20µA

GENERAL

Frequency Band:

433MHz(Default), 450MHz~915MHz(customized)

Communication Mode:

Half-duplex

Channel:

8(Default), 16/32(customized)

Interface:

RS-232/RS-485/USB/TTL optional

PHYSICAL PROPERTIES

Size:

80mm*45mm*19mm (without antenna port)

Antenna Impedance:

50Ω SMA (multiple antenna options available)

Operating Temperature:

-35~+75 C

Frequency Stability;

±2.5ppm
