Specifications
Brand Name :
Kingdelong
Model Number :
KDL
Place of Origin :
Anping,China
Certification :
ISO9001, ISO14001, ISO45001, SGS
MOQ :
30sqm
Price :
$75-$110
Packaging Details :
rolling around paper tube first, moisture-proof paper outside or plastic fabrics, customized packing available
Delivery Time :
5 to 7 days, if in stock
Payment Terms :
D/P,T/T,D/A
Supply Ability :
10000sqm
Product Name :
Stainless Steel Plain Weave Woven Wire Mesh Screen for Separation and Filtration
Material :
Stainless steel 201, 202, 304, 304L, 316, 316L, etc
Hole shape :
Square, Rectangular
Weaving type :
Plain, Twilled, Dutch, Cripmed,etc
Edge preparation :
Selvage, Raw Edge,etc
Surface treatment :
Galvanized, PVC Coated, Epoxy Coated ,etc
Applications :
Quarry Screen, Crusher Screen, Seperation Or Filtration In Chemical Oil, Industries And So On.
Features :
Abrasion Resistant, Heavy Impact Resistant, Corrosion Resistant,Long Service Life.
Description
Stainless Steel Plain Weave Woven Wire Mesh Screen
A high-quality, versatile material engineered for separation and filtration applications across industrial and commercial sectors. Crafted from premium-grade stainless steel, this mesh combines strength, durability, and corrosion resistance to meet demanding industrial requirements.
Product Specifications
Mesh Wire Dia. (inches) Wire Dia. (mm) Effective area %
1 0.135 3.5 21.97
5 0.08 2 3.04
10 0.02 0.5 2.03
50 0.009 0.23 0.28
100 0.0045 0.11 0.15
180 0.002 0.05 0.09
200 0.002 0.05 0.076
250 0.0016 0.04 0.061
270 0.0014 0.04 0.055
300 0.0012 0.03 0.053
325 0.0014 0.04 0.043
400 0.001 0.025 0.038
500 0.001 0.025 0.028
635 0.0009 0.022 0.015
Key Features
  • Material: High Tensile Spring Steel, Manganese Steel, and Stainless Steel (304/316 grades)
  • Weaving Types: Plain, Twilled, Dutch, Crimped patterns available
  • Hole Shapes: Square or Rectangular openings
  • Surface Treatments: Galvanized, PVC Coated, Epoxy Coated options
  • Performance: Abrasion resistant, heavy impact resistant, corrosion resistant
Stainless Steel Woven Wire Mesh Screen with Square and Rectangular Holes for Galvanized Industrial Filtration
Technical Advantages
Superior Corrosion Resistance
  • Constructed with chromium-nickel alloys (18% Cr/8% Ni in 304; 16% Cr/10% Ni/2% Mo in 316)
  • Withstands pH extremes (2-12), chlorides, and UV exposure
  • Ideal for marine architecture, chemical processing, and food contact surfaces
Engineered for Strength & Longevity
  • Tensile strength: 500-700 MPa (varies by wire diameter)
  • Maintains dimensional stability under continuous vibration/impact
  • 3-5X longer service life vs. carbon steel alternatives
Precision Filtration Performance
  • Mesh range: 0.025mm-12.7mm aperture sizes (2 mesh to 500 mesh)
  • ±3% aperture tolerance for accurate particle separation
  • Compliant with FDA/EC1935, API/ISO 9044, and GMP standards
Industry Applications
Our woven wire mesh screen is widely used across multiple industries including:
  • Mining & Aggregates: Trommel screens, scalping decks
  • Water Treatment: Membrane pre-filters, wedge wire underdrains
  • Aerospace: Composite material layup templates
  • Chemical Processing: Catalyst retention, filtration systems
  • Food & Pharmaceutical: Powder sieving, micron filtration
Packaging & Shipping
Each Woven Wire Mesh Screen is carefully packaged in sturdy cardboard boxes with protective wrapping to ensure damage-free transit. Standard and expedited shipping options are available with tracking provided for all orders.
  • Minimum Order: 30sqm
  • Lead Time: 5-7 days for in-stock items
  • Certifications: ISO9001, ISO14001, ISO45001, SGS
