High Manganese Steel Curved Mining Crimped Mesh
High Manganese Steel Curved Mining Crimped Mesh
High Manganese Steel Curved Mining Crimped Mesh
High Manganese Steel Curved Mining Crimped Mesh
High Manganese Steel Curved Mining Crimped Mesh
High Manganese Steel Curved Mining Crimped Mesh
Specifications
Brand Name :
CHANGTE
Model Number :
HBCT-C021
Certification :
ISO9001:2015
Place of Origin :
CHINA,HEBEI
MOQ :
10M
Price :
10.0usd/m
Payment Terms :
Consultation and communication decision
Supply Ability :
200tons
Delivery Time :
5 - 8 days
Packaging Details :
Wooden pallets or packed according to customer's requirement
Name :
Stainless Steel Mesh Screen,double crimped wire mesh,mine screen mesh
Material :
45Mn,65Mn
Type :
Crimped Wire Mesh,Weave Wire Mesh,Wire Cloth,Crimped Screen,Reinforced Mesh
Weaving type :
double crimp,single intermediate crimp,flat tope ,lock crimp
Wire diameter :
0.5-10mm,0.025-1mm,0.7mm-6.0mm,Requirement,40-600micron
Hole shape :
Square Hole,as per requirement
Width :
customized,1-5m,1.2m,0.5-2.2m,0.5-3m
Length :
30m per roll or as required,customized,30m,50m/roll at customer request,0.5-5.8m
feature :
high durability ,precision ,impact resistance ,abrasion resistance
Color :
red
Application :
Filters,Screen,Woven Wire Mesh,Protecting Mesh,decorative wire mesh
Usage :
coal industrial,screening coarse material,Speaker Grills,chicken wire mesh,construction industrial
Description

Wear-Resisting High Manganese Steel Curve Mining crimped wire mesh

1.Material: black wire, spring steel wire, manganese steel wire and stainless steel wire.

2.Surface treatment: galvanized or painted.

3.Wire diameter: 0.71mm - 12.5mm.

4.Mesh size: 1mm - 100mm.

5.Hole type: square, rectangular and long slot.

6.Weaving type:
Plain weave.
Pre-crimped.
Flat top.
Intermediate crimped.
Lock crimped.

7.Application:
Mainly used as screen mesh, it is widely used in many industries, such as mining screen, quarrying screen, the screen deck, screen wire for stone crusher, Classifying Trommel; Vibrating screen; Road construction equipment; The Asphaltum mix round equipment and the mine vibrating screens, chemical industry, pharmacy, machinery, protection, construction.

WIRE DIA APERTURE WEIGHT
0.75 1.00 4.29
1.00 1.50 5.33
1.50 2.00 8.57
2.00 3.00 10.67
3.00 4.00 17.15
3.00 5.00 15.00
3.50 6.00 17.20
4.00 8.00 17.44
4.00 10.00 14.95
4.50 12.00 16.05
4.50 12.50 15.58
4.50 14.00 14.32
5.00 16.00 15.57
5.50 18.00 16.84
5.50 19.00 16.15
5.50 20.00 15.52
6.50 22.00 19.39
6.50 24.00 18.12
6.50 25.00 17.55
6.50 28.00 16.02
7.00 32.00 16.44
7.50 35.00 17.31
7.50 38.00 16.17
7.50 40.00 15.49
7.50 45.00 14.02
8.00 50.00 14.43
9.00 63.00 14.72
9.00 75.00 12.61
11.00 100.00 14.26


High Manganese Steel Curved Mining Crimped Mesh
