PCD Diamond Spiral Router Bit with 10 mm Cutting Diameter 16 mm Cutting Height and 12.7 mm Shank Diameter for CNC Woodworking
PCD Diamond Spiral Router Bit with 10 mm Cutting Diameter 16 mm Cutting Height and 12.7 mm Shank Diameter for CNC Woodworking
PCD Diamond Spiral Router Bit with 10 mm Cutting Diameter 16 mm Cutting Height and 12.7 mm Shank Diameter for CNC Woodworking
PCD Diamond Spiral Router Bit with 10 mm Cutting Diameter 16 mm Cutting Height and 12.7 mm Shank Diameter for CNC Woodworking
PCD Diamond Spiral Router Bit with 10 mm Cutting Diameter 16 mm Cutting Height and 12.7 mm Shank Diameter for CNC Woodworking
PCD Diamond Spiral Router Bit with 10 mm Cutting Diameter 16 mm Cutting Height and 12.7 mm Shank Diameter for CNC Woodworking
Specifications
Delivery Time :
7~35 work days
Application :
CNC woodworking and panel processing
Model Number :
D10 × H16 × S12.7
Size :
D10 × H16 × S12.7
Price :
Contact us for a quote！
Packaging Details :
packed in standard carton box
Cutting Height :
16 mm
Supply Ability :
100pcs/30 work days
Cutting Material :
PCD (Polycrystalline Diamond)
Payment Terms :
T/T
Shank Diameter :
12.7 mm (1/2")
Place of Origin :
China
Brand :
YD
Brand Name :
YD
Product Type :
PCD Diamond Spiral Router Bit
MOQ :
5 PCS
Cutting Diameter :
10 mm
Description
PCD Diamond Spiral Router Bit D10 × H16 × S12.7

The PCD Diamond Spiral Router Bit is a high-performance CNC cutting tool designed for precision machining of wood-based panels and other abrasive materials. Manufactured with polycrystalline diamond (PCD) cutting edges, this spiral router bit offers excellent wear resistance, long service life, and consistent cutting performance.

With a 10 mm cutting diameter, 16 mm cutting height, and 12.7 mm shank diameter, it is suitable for a wide range of CNC woodworking applications, including routing, profiling, slotting, and contour cutting.

Compared with conventional carbide router bits, PCD tooling provides significantly higher wear resistance when machining abrasive materials such as MDF, HDF, particle board, melamine-coated panels, and laminated boards. It is particularly suitable for high-volume production where long tool life and reduced tool-change frequency are important.

Key Features
  • PCD diamond cutting edges for superior wear resistance
  • Long service life for high-volume CNC machining
  • Excellent cutting stability and precision
  • Suitable for abrasive wood-based materials
  • Reduces tool-change frequency and production downtime
  • Ideal for CNC routers and woodworking machining centers
Specifications
  • Product Type: PCD Diamond Spiral Router Bit
  • Cutting Diameter: 10 mm
  • Cutting Height: 16 mm
  • Shank Diameter: 12.7 mm (1/2")
  • Cutting Material: PCD (Polycrystalline Diamond)
  • Application: CNC woodworking and panel processing
  • Applications: MDF, HDF, particle board, melamine board, laminated panels, plywood, and other abrasive composite materials.
