PH120 2layer Hydraulic Plywood Short Cycle Melamine Laminating Hot Heat Press Machine
PH120 2layer Hydraulic Plywood Short Cycle Melamine Laminating Hot Heat Press Machine
PH120 2layer Hydraulic Plywood Short Cycle Melamine Laminating Hot Heat Press Machine
PH120 2layer Hydraulic Plywood Short Cycle Melamine Laminating Hot Heat Press Machine
PH120 2layer Hydraulic Plywood Short Cycle Melamine Laminating Hot Heat Press Machine
PH120 2layer Hydraulic Plywood Short Cycle Melamine Laminating Hot Heat Press Machine
PH120 2layer Hydraulic Plywood Short Cycle Melamine Laminating Hot Heat Press Machine
PH120 2layer Hydraulic Plywood Short Cycle Melamine Laminating Hot Heat Press Machine
PH120 2layer Hydraulic Plywood Short Cycle Melamine Laminating Hot Heat Press Machine
PH120 2layer Hydraulic Plywood Short Cycle Melamine Laminating Hot Heat Press Machine
PH120 2layer Hydraulic Plywood Short Cycle Melamine Laminating Hot Heat Press Machine
PH120 2layer Hydraulic Plywood Short Cycle Melamine Laminating Hot Heat Press Machine
Specifications
Place of Origin :
Shandong, China
Brand Name :
PHOENIX MACHINERY
Condition :
New
Machine Type :
Hot Press Machine
Video outgoing-inspection :
Provided
Machinery Test Report :
Provided
Marketing Type :
New Product 2024
Warranty of core components :
1 Year
Core Components :
PLC, Engine, Bearing, Gearbox, Motor, Pressure vessel, Gear, Pump
Warranty :
1 Year
Weight (KG) :
8000 KG
Power (kW) :
5.5kw
Key Selling Points :
Easy to Operate
Showroom Location :
None
Applicable Industries :
Building Material Shops, Manufacturing Plant, Food & Beverage Factory, Construction works , Advertising Company
Name :
hydraulic hot press machine
Product name :
plywood hot press
Panel Width :
≥60mm
Total pressure :
1200KN / 120 T
Working Layers :
2
Cylinder :
6*100mm
Heating way :
Electric heating with thermic oil
Max temperature :
120℃
Platen size :
3000*1300*42mm(Covered with mylar)
Application :
Wood Process
Price :
$12,500.00/sets 1-4 sets
MOQ :
1 set
Description
PH120 2layer Hydraulic Plywood Short Cycle Melamine Laminating Hot Heat Press Machine
Products Description
PH120 2layer Hydraulic Plywood Short Cycle Melamine Laminating Hot Heat Press Machine
PH120 2layer Hydraulic Plywood Short Cycle Melamine Laminating Hot Heat Press Machine
Specification
PH120 2layer Hydraulic Plywood Short Cycle Melamine Laminating Hot Heat Press Machine
Model
PH120 2layer
Panel Width
≥60mm
Total pressure
1200KN / 120 T
Working Layers
2
Cylinder
6*100mm
Heating way
Electric heating with thermic oil
Max temperature
120℃
Hydraulic Motor power
5.5kw
Hot Oil Pump power
1.5kw
Thermal Oil funace power
36kw
Platen size
3000*1300*42mm(Covered with mylar)
Overall dimension
4150*1670*2000mm
Weight
8000kg
PH120 2layer Hydraulic Plywood Short Cycle Melamine Laminating Hot Heat Press Machine
PH120 2layer Hydraulic Plywood Short Cycle Melamine Laminating Hot Heat Press Machine
PH120 2layer Hydraulic Plywood Short Cycle Melamine Laminating Hot Heat Press Machine
PH120 2layer Hydraulic Plywood Short Cycle Melamine Laminating Hot Heat Press Machine
PH120 2layer Hydraulic Plywood Short Cycle Melamine Laminating Hot Heat Press Machine
PH120 2layer Hydraulic Plywood Short Cycle Melamine Laminating Hot Heat Press Machine
Packing Delivery
1. Outside package: Standard marine export plywood cases.
2. Inner package: Stretch film and plastic film for humidity.
We can package according to your requests
PH120 2layer Hydraulic Plywood Short Cycle Melamine Laminating Hot Heat Press Machine
Product Name
woodworking hot press machine with thermal oil
Brand
PHOENIX EQUIPMENT
Customized
color, logo, voltage
MOQ
1 set
Package
plywood wooden box
Payment terms
Alibaba Trade Assurance, T/T, Alipay
Usage
furniture production factory, wooden door factory, artificial board of second operation veneering, to hot-pressing bonding panel furniture, building partition wall, wooden door, fireproof door surface materials. In a variety of man-made board, such as:plywood, core-board, MDF, particle board’s surface pressing all kinds of decorative materials, decorative fabric, wood veneer,PVC, etc., It can also be used for veneer drying, leveling, color decoration wood leveling, finalize the design and the effect is remarkable.
