WP-182 Automatic Dual Cylinder Hydraulic Log Splitter for Firewood Processing at Home
WP-182 Automatic Dual Cylinder Hydraulic Log Splitter for Firewood Processing at Home
WP-182 Automatic Dual Cylinder Hydraulic Log Splitter for Firewood Processing at Home
WP-182 Automatic Dual Cylinder Hydraulic Log Splitter for Firewood Processing at Home
WP-182 Automatic Dual Cylinder Hydraulic Log Splitter for Firewood Processing at Home
WP-182 Automatic Dual Cylinder Hydraulic Log Splitter for Firewood Processing at Home
WP-182 Automatic Dual Cylinder Hydraulic Log Splitter for Firewood Processing at Home
WP-182 Automatic Dual Cylinder Hydraulic Log Splitter for Firewood Processing at Home
WP-182 Automatic Dual Cylinder Hydraulic Log Splitter for Firewood Processing at Home
WP-182 Automatic Dual Cylinder Hydraulic Log Splitter for Firewood Processing at Home
WP-182 Automatic Dual Cylinder Hydraulic Log Splitter for Firewood Processing at Home
WP-182 Automatic Dual Cylinder Hydraulic Log Splitter for Firewood Processing at Home
Specifications
Place of Origin :
Shandong, China
Brand Name :
PHOENIX MACHINERY
Condition :
New
Machine Type :
log splitter
Video outgoing-inspection :
Provided
Machinery Test Report :
Provided
Marketing Type :
New Product 2024
Warranty of core components :
1 Year
Core Components :
Motor
Warranty :
1 Year
Weight (KG) :
195 KG
Key Selling Points :
Easy to Operate
Showroom Location :
None
Applicable Industries :
Manufacturing Plant, Farms, Home Use, Retail, Construction works
Name :
household log splitter machine
Product name :
Strong power wood spliter
Power Type :
Electric
Usage :
splittering and cutting
Horizontal/Vertical :
Horizontal
Splitting stroke Length :
680mm(Customizable)
Production dimension :
2230*680*960mm
Max. tonnage :
18T
Control handle :
Hands with safety switch
Splitting method :
Hydraulically 2 ways/4 ways
Price :
$960.00/sets 1-49 sets
MOQ :
1 set
Description
WP-182 Automatic Dual Cylinder Hydraulic Log Splitter for Firewood Processing at Home
Products Description
WP-182 Automatic Dual Cylinder Hydraulic Log Splitter for Firewood Processing at Home
WP-182 Automatic Dual Cylinder Hydraulic Log Splitter for Firewood Processing at Home
Specification
WP-182 Automatic Dual Cylinder Hydraulic Log Splitter for Firewood Processing at Home
Production dimension
2230×680×960mm
Wooden bracket
there are
Net weight (KG)
195
Working pressure
20MP-32MP can be adjusted
Packing size (mm)
1410×580×715
OEM
Acceptable
Total weight of packing (KG)
225
Customer warranty
1year
Horizontal/Vertical
Horizontal
Engine brand
RATO
Splitting method
Hydraulically 2 ways/4 ways
Engine type
Air-cool and four-stroke gasoline engine, OHV
Cycle
8S
Engine displacement
7P 202CC
Oil pump model/flow L/min
CBNA-13/1.8D
Axial direction of engine
Horizontal axis
Control valve（1）
26.4GAL three-position automatic return
Start engine
Electric/recoil
Control valve（2）
10.5GAL three-position automatic return
Rated torque* (N.m@3060rpm)
12
Max. tonnage
18T
Cylinder body
Single cylinder with sleeve made of cast iron
Hydraulic oil No.
32#/46#
Engine oil tank capacity
3.6L
Tires
3.50-5
Cylinder diameter (mm)
70
Min. oil level of hydraulic oil
14L
Machine Oil volume
0.55
Max. oil level of hydraulic oil
20L
Engine Stroke (mm)
55
Inner diameter of cylinder (mm)
80
Engine Net weight (LBS)
16
Splitting stroke Length (mm)
680(Customizable)
Engine specification (L*W*H mm)
390*320*345
WP-182 Automatic Dual Cylinder Hydraulic Log Splitter for Firewood Processing at Home
WP-182 Automatic Dual Cylinder Hydraulic Log Splitter for Firewood Processing at Home
WP-182 Automatic Dual Cylinder Hydraulic Log Splitter for Firewood Processing at Home
WP-182 Automatic Dual Cylinder Hydraulic Log Splitter for Firewood Processing at Home
Packing Delivery
1. Outside package: Standard marine export plywood cases.
2. Inner package: Stretch film and plastic film for humidity.
We can package according to your requests
WP-182 Automatic Dual Cylinder Hydraulic Log Splitter for Firewood Processing at Home
Product Name
Wood cutting-splitting machine
Brand
PHOENIX EQUIPMENT
Customized
color, logo, voltage
MOQ
1 set
Package
plywood wooden box
Payment terms
Alibaba Trade Assurance, T/T, Alipay
Usage
wood Splitter
