Specifications
CNC or Not :
CNC
Condition :
New
Machine Type :
6 Surfaces
Max.Working Width(mm) :
750mm
Video outgoing-inspection :
Provided
Machinery Test Report :
Provided
Marketing Type :
New Product 2023
Warranty of core components :
1 Year
Core Components :
Motor
Place of Origin :
Shandong, China
Brand Name :
PHOENIX MACHINERY
Dimension(L*W*H) :
4350*2500*1560mm
Warranty :
1 Year
Weight (KG) :
3000 KG
Power (kW) :
52
Key Selling Points :
Easy to Operate
Applicable Industries :
Hotels, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Home Use, Construction works , Advertising Company
Showroom Location :
None
Product name :
six-row drill machine
Name :
Automatic Feeding Boring Machine
Function :
Multi Spindle Drilling Holes
Application :
Wood Drilling Furniture Making
Machining length :
300 - 2500mm
Processing thickness :
8 - 50mm
Machining width :
120-750mmmm
Drilling depth :
40mm
Number of servos :
10
Maximum drilling diameter :
13 (adjacent drill) 35 (single drill)
Packaging Details :
1. Outside package: Standard marine export plywood cases.
2. Inner package: Stretch film and plastic film for humidity.
We can package according to your requests
Supply Ability :
100 Set/Sets per Month
Price :
$85,000.00/sets >=1 sets
MOQ :
1 set
Description
Advanced Multi Row Line Wood CNC Drilling Machine for 8 50mm Processing Thickness
Advanced Multi Row Line Wood CNC Drilling Machine for 8 50mm Processing Thickness
Advanced Multi Row Line Wood CNC Drilling Machine for 8 50mm Processing Thickness
Advanced Multi Row Line Wood CNC Drilling Machine for 8 50mm Processing Thickness
Specification
Machining length
300 - 2500mm
Processing thickness
8 - 50mm
Machining width
120-750mmmm
Drilling depth
40mm
Number of vertical drilling rows on top
4
Number of vertical drilling rows on bottom
6
Left/Right Horizontal Drill Rows
1/1
Total number of drill shafts
264
Number of servos
10
Maximum drilling diameter
13 (adjacent drill) 35 (single drill)
Y-axis hole spacing
32 - 672mm
X-axis hole spacing
300 - 2500mm
Processing speed
16-20Piece/min
Total power
52kw
Packing Delivery
1. Outside package: Standard marine export plywood cases.
2. Inner package: Stretch film and plastic film for humidity.
We can package according to your requests
Advanced Multi Row Line Wood CNC Drilling Machine for 8 50mm Processing Thickness
Product Name
Woodworking Machinery Panel Furniture Wooden Auto feeding 12 Row line CNC drilling machine for wood
Brand
PHOENIX EQUIPMENT
Customized
color, logo, voltage
MOQ
1 set
Package
plywood wooden box
Payment terms
Alibaba Trade Assurance, T/T, Alipay
user
solid wood panel , chipboard , ABS board、PVC board and other boards which have the similar structure and hardness
Advanced Multi Row Line Wood CNC Drilling Machine for 8 50mm Processing Thickness
