Horizontal Drilling MZB73214 Multi Spindle Line Boring Machine with 21 Bits * 4 Lines
Horizontal Drilling MZB73214 Multi Spindle Line Boring Machine with 21 Bits * 4 Lines
Horizontal Drilling MZB73214 Multi Spindle Line Boring Machine with 21 Bits * 4 Lines
Horizontal Drilling MZB73214 Multi Spindle Line Boring Machine with 21 Bits * 4 Lines
Horizontal Drilling MZB73214 Multi Spindle Line Boring Machine with 21 Bits * 4 Lines
Horizontal Drilling MZB73214 Multi Spindle Line Boring Machine with 21 Bits * 4 Lines
Horizontal Drilling MZB73214 Multi Spindle Line Boring Machine with 21 Bits * 4 Lines
Horizontal Drilling MZB73214 Multi Spindle Line Boring Machine with 21 Bits * 4 Lines
Horizontal Drilling MZB73214 Multi Spindle Line Boring Machine with 21 Bits * 4 Lines
Horizontal Drilling MZB73214 Multi Spindle Line Boring Machine with 21 Bits * 4 Lines
Horizontal Drilling MZB73214 Multi Spindle Line Boring Machine with 21 Bits * 4 Lines
Horizontal Drilling MZB73214 Multi Spindle Line Boring Machine with 21 Bits * 4 Lines
Specifications
CNC or Not :
Normal
Condition :
New
Line Number :
Four
Video outgoing-inspection :
Provided
Machinery Test Report :
Provided
Marketing Type :
New Product 2024
Warranty of core components :
1 Year
Core Components :
PLC, Engine, Bearing, Motor
Place of Origin :
Shandong, China
Brand Name :
PHOENIX EQUIPMENT
Voltage :
380V 50HZ (Customized voltage)
Dimension(L*W*H) :
3500*2500*1550mm
Warranty :
1 Year
Weight (KG) :
1200 KG
Power (kW) :
1.5kw * 4
Key Selling Points :
High-accuracy
Applicable Industries :
Hotels, Building Material Shops, Machinery Repair Shops, Other, furniture factory
Showroom Location :
United States, Italy, France, Germany, Viet Nam
Product name :
Horizontal Drilling 4 Rows Boring Machine
Function :
table drill bench drill press
Vertical machining holes distance :
140-2550mm
Number of auger spindle :
21 bits * 4lines
Maximum Drilling Depth :
60mm
Air Pressure :
0.6-0.8MPa
Packing Size :
3600*1220*1700mm
Installation size :
3500*2500*1550mm
Min center distance between spindles :
32mm
Price :
$6,400.00/sets 1-4 sets
MOQ :
1 set
Description
Horizontal Drilling MZB73214 Multi Spindle Line Boring Machine with 21 Bits * 4 Lines
Products Description
Horizontal Drilling MZB73214 Multi Spindle Line Boring Machine with 21 Bits * 4 Lines
Horizontal Drilling MZB73214 Multi Spindle Line Boring Machine with 21 Bits * 4 Lines
Specification
Model
MZB73214
Maximum Drilling Diameter
Max.=35mm(Single drilling)
D=13mm(Multiple drilling)
Maximum Drilling Depth
60mm
Vertical machining holes distance
140-2550mm
Number of auger spindle
21 bits * 4lines
Spindle speed
2840r/min
Installed power
1.5kw * 4
Air pressure
0.6-0.8MPa
Suitable voltage
380V 50HZ (Customized voltage)
Min center distance between spindles
32mm
Net weight
1200KG
Installation size
3500*2500*1550mm
Packing Size
3600*1220*1700mm
Packing Delivery
1. Outside package: Standard marine export plywood cases.
2. Inner package: Stretch film and plastic film for humidity.
We can package according to your requests
Horizontal Drilling MZB73214 Multi Spindle Line Boring Machine with 21 Bits * 4 Lines
Product Name
Woodworking 4 Rows Boring Machine For Furniture Vertical Horizontal Drilling
Brand
PHOENIX EQUIPMENT
Customized
color, logo, voltage
MOQ
1 set
Package
plywood wooden box
Payment terms
Alibaba Trade Assurance, T/T, Alipay
Usage
Suitable for all kinds of density boards, particleboard, based panels,PVC panels, organic glass plates and solid wood boards such as the drill
