Wood Panel Furniture Horizontal Multi Spindle Boring Machine with 750W 400W Voltage
Wood Panel Furniture Horizontal Multi Spindle Boring Machine with 750W 400W Voltage
Wood Panel Furniture Horizontal Multi Spindle Boring Machine with 750W 400W Voltage
Wood Panel Furniture Horizontal Multi Spindle Boring Machine with 750W 400W Voltage
Wood Panel Furniture Horizontal Multi Spindle Boring Machine with 750W 400W Voltage
Wood Panel Furniture Horizontal Multi Spindle Boring Machine with 750W 400W Voltage
Wood Panel Furniture Horizontal Multi Spindle Boring Machine with 750W 400W Voltage
Wood Panel Furniture Horizontal Multi Spindle Boring Machine with 750W 400W Voltage
Wood Panel Furniture Horizontal Multi Spindle Boring Machine with 750W 400W Voltage
Wood Panel Furniture Horizontal Multi Spindle Boring Machine with 750W 400W Voltage
Wood Panel Furniture Horizontal Multi Spindle Boring Machine with 750W 400W Voltage
Wood Panel Furniture Horizontal Multi Spindle Boring Machine with 750W 400W Voltage
Specifications
CNC or Not :
CNC
Condition :
New
Machine Type :
Side hole drilling machine
Max.Working Width(mm) :
2500
Video outgoing-inspection :
Provided
Machinery Test Report :
Provided
Marketing Type :
New Product 2024
Warranty of core components :
1 Year
Core Components :
Motor
Place of Origin :
Shandong, China
Brand Name :
PHOENIX EQUIPMENT
Voltage :
750W+400W
Dimension(L*W*H) :
3000*1700*1400mm
Warranty :
1 Year
Weight (KG) :
900 KG
Power (kW) :
2.2kw*2
Key Selling Points :
Easy to Operate
Applicable Industries :
Building Material Shops, Manufacturing Plant, Construction works , Food & Beverage Shops, Other
Showroom Location :
None
Product name :
Automatic cnc side hole drilling boring machine
Function :
wood drilling machine
Usage :
Drilling Wood Hole
Keyword :
Wood Drilling Cnc Machine
Working table length :
2500mm
Working table height :
800mm
Working speed :
150m/min
Working air pressure :
0.6Mpa
Application :
Drilling Wood Panel Holes
Price :
$3,600.00/sets 1-4 sets
MOQ :
1 set
Description
Wood Panel Furniture Horizontal Multi Spindle Boring Machine with 750W 400W Voltage
Products Description
Wood Panel Furniture Horizontal Multi Spindle Boring Machine with 750W 400W Voltage
Wood Panel Furniture Horizontal Multi Spindle Boring Machine with 750W 400W Voltage
Specification
Model
CK-3000B
Working table length
2500mm
Working table height
800mm
Spindle power
2.2kw*2
Spindle speed
18000rpm/min
Working speed
150m/min
Servo drive motor
750W+400W
Working air pressure
0.6Mpa
Machine size
3000*1700*1400mm
Weight
900kgs
Packing Delivery
1. Outside package: Standard marine export plywood cases.
2. Inner package: Stretch film and plastic film for humidity.
We can package according to your requests
Wood Panel Furniture Horizontal Multi Spindle Boring Machine with 750W 400W Voltage
Product Name
Horizontal Multi Spindle Boring Machine Side Drilling Machine
Brand
PHOENIX EQUIPMENT
Customized
color, logo, voltage
MOQ
1 set
Package
plywood wooden box
Payment terms
Alibaba Trade Assurance, T/T, Alipay
Usage
specially play the trinity hole, blind hole, wood pin hole and slot.
