Specifications
Condition :
New
Type :
Rip Saw
Use :
Woodworking
Style :
Horizontal
Place of Origin :
Shandong, China
Brand Name :
Phoenix Equipment
Dimension(L*W*H) :
3420*1550*1530mm
Warranty :
1 Year
Application :
Woodworking Factory
Weight (KG) :
2100 KG
Power (kW) :
22KW*2
Key Selling Points :
Easy to Operate
Max.Working Width(mm) :
200mm
Max.Working Height(mm) :
200mm
Rip Saw Type :
Multi-blade
Applicable Industries :
Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Farms, Home Use, Printing Shops, Construction works , Other, Woodworking Factory
Marketing Type :
New Product 2024
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
Core Components :
Motor
Name :
wood rip saw
Product name :
Plank Cutting Multiple Blade Rip Saw
Usage :
Log cutting
Function :
Round wood slicing
Sawing Log Diameter :
60mm--200mm
Sawing Log Length :
650---4000mm
Spindle speed :
3300r/min
Feed speed( Frequency Control ) :
0-10m/min
Saw blade diameter :
305mm
Spindle diameter :
50mm
Price :
$5,600.00/sets 1-9 sets
MOQ :
1 set
Description
PYM200 Woodworking Circular Saw 200mm Multi Blade Rip Saw for Building Material Shops
Products Description
PYM200 Woodworking Circular Saw 200mm Multi Blade Rip Saw for Building Material Shops
Specification
PYM200 Woodworking Circular Saw 200mm Multi Blade Rip Saw for Building Material Shops
Model
PYM200
PYM250
PYM-300
PYM-350
PYM-400
Sawing Log Diameter
60mm--200mm
80---250mm
100---300mm
100---350mm
120---400mm
Sawing Log Length
650---4000mm
700---4000mm
750--4000mm
800--4000mm
900-4000mm
Spindle speed
3300r/min
3300r/min
2500r/min
2300r/min
2300r/min
Main Motor power
22KW*2
22KW+30KW
30KW+37KW
37KW*2
45KW*2
Feeding Motor
1.5KW*2
1.5KW*2
1.5KW*2
1.5KW*2
1.5KW*2
Feed speed
( Frequency Control )
0-10m/min
0-10m/min
0-10m/min
0-10m/min
0-10m/min
Saw blade diameter
305mm
355mm
405mm
455mm
500mm
Spindle diameter
50mm
50mm
70mm
70mm
70mm
Cooling mode
Spindle water cooling
Spindle water cooling
Spindle water cooling
Spindle water cooling
Spindle water cooling
Overall dimension
3420*1550*1530mm
3500*1550*1530mm
3800*1680*1600mm
3860*1680*1600mm
3900*1680*1600mm
Machine weight
2100kg
2500kg
2800kg
3200kg
3400kg
Remarks optional
Accept customization
Packing Delivery
1. Outside package: Standard marine export plywood cases.
2. Inner package: Stretch film and plastic film for humidity.
We can package according to your requests
PYM200 Woodworking Circular Saw 200mm Multi Blade Rip Saw for Building Material Shops
Product Name
woodworking round log cutting saw multi blade rip saw machine multiple rip saw machine
Brand
PHOENIX EQUIPMENT
Customized
color, logo, voltage
MOQ
1 set
Package
plywood wooden box
Payment terms
Alibaba Trade Assurance, T/T, Alipay
Usage
cut wood logs into boards
