Specifications
Brand Name :
HOLD
Model Number :
HD855J
MOQ :
1
Payment Terms :
L/C, T/T
Delivery Time :
15-30 Work days
Description

Minimum board size: 150×40mm (four-side edge banding with tracking), 120×40mm (long-side edge banding).

Specially designed pre-milling mechanism for narrow end heads of workpieces, capable of milling narrow board end heads of ≥40mm.

The frame adopts a heavy-duty structure, processed by CNC to ensure the flatness of the table.

The distance between two sets of guide rail columns is densified, ensuring smoother board transportation and better edge scraping effect.

Independent motor control for glue application and edge pressing to avoid the phenomenon of "less glue at the beginning and more glue at the end" of boards.

Gluing system 1: upper PUR gluing system;

Gluing system 2: EVA gluing system

Item HD855J Item HD855J
Electrical lifting √ Thickness of panel 10-60mm
Total power 33kw Length of panel ≥120mm (with corner rounding ≥150mm)
Dimension 10450x1000x1800mm Width of panel ≥40mm
Feeding speed 16m-20m-23m/min Working pressure 0.6Mpa
Thickness of tape 0.4-3mm Min. Size of panel 150×40mm (four-sided edge banding, with tracking capability)
120×40mm (edge banding on the long side)

Fully intelligent control system

Automatic High-Speed Narrow Edge Banding Machine HD855J

Pre-Milling

Automatic High-Speed Narrow Edge Banding Machine HD855J

PUR Gluing system

Automatic High-Speed Narrow Edge Banding Machine HD855J

Glue Application Unit Two: Hot Melt Adhesive Application System + Rapid Melting + Automatic Glue Extraction Machine

Automatic High-Speed Narrow Edge Banding Machine HD855J

Five-Roller Pressing

Automatic High-Speed Narrow Edge Banding Machine HD855J

Two rails three motors end cutting

Automatic High-Speed Narrow Edge Banding Machine HD855J

Four-Blade High-Speed Corner Rounding

Automatic High-Speed Narrow Edge Banding Machine HD855J

narrow edge scraping

Automatic High-Speed Narrow Edge Banding Machine HD855J

Wire Breakage Mechanism + Flexible Edge Scraper + Cleaning Agent Device

Automatic High-Speed Narrow Edge Banding Machine HD855J
