Specifications
Brand Name :
qipang
Model Number :
TC500/630/800/1000
Certification :
SGS
Place of Origin :
Shanghai
MOQ :
MOQ≥1
Price :
Negotiable
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
500 PC/per day
Delivery Time :
15 working days
Packaging Details :
Carton, wooden box
Name :
Qipang
Type :
TC500/630
suitable Material :
cable wire
Weight :
350 kg
Speed :
MAX 200 m/min
Power :
4KW
Lifting power :
0.75KW
Warranty :
about 1 year
Coil diameter :
PN400-PN630
Voltage :
220V/380V
Description

qipang Automatic cable winding and coiling Machine wire rewinding machine cable manufacturing equipment

1. TC 300 TAKE UP AND PAY OFF MACHINE

qipang Automatic cable winding Machine wire rewinding machine coiling cable manufacturing equipment qipang Automatic cable winding Machine wire rewinding machine coiling cable manufacturing equipment

Model TC300 TC 400 TC 500
Wire diameter φ0.1-φ3mm φ1-φ5mm φ0.1-φ5mm
Spoolsize(flange OD) ≤φ300mm ≤φ400mm ≤φ500mm
Coiling speed 110r/min 280r/min 280r/min
Take-up motor 1*0.18KW 1*0.37KW 1*0.37KW
Winding type Traverse unit Traverse unit Traverse unit
Winding tension 8N/M 10N/M 10N/M
Load bearing 20KG 30KG 30KG

2. TC 300 REWINDING MACHINE

qipang Automatic cable winding Machine wire rewinding machine coiling cable manufacturing equipment qipang Automatic cable winding Machine wire rewinding machine coiling cable manufacturing equipment

3. QP 500 WINDING MACHINE

qipang Automatic cable winding Machine wire rewinding machine coiling cable manufacturing equipment qipang Automatic cable winding Machine wire rewinding machine coiling cable manufacturing equipment

Model QP 300 QP 400 QP 500
Wire diameter φ0.1-φ3mm φ1-φ5mm φ0.1-φ5mm
Spoolsize(flange OD) ≤φ300 ≤φ400 ≤φ500
Coiling speed 280r /min 280r /min 280r /min
Take-up motor 1*0.37KW 1*0.37KW 1*0.37KW
Winding type Traverse unit Traverse unit Traverse unit
Winding tension 8N/M 10N/M 10N/M
Load bearing 40KG 43KG 50KG

4. QP 630-1000 CABLE WINDING MACHINE

qipang Automatic cable winding Machine wire rewinding machine coiling cable manufacturing equipment qipang Automatic cable winding Machine wire rewinding machine coiling cable manufacturing equipment

Model

 QPX630 QPX 800 QPX 1000 QPX 1250

Take-up line diameter

 φ2-φ5mm φ2-φ6mm φ3-φ12mm φ3-φ18mm

Take-up reel

 ≤630mm ≤800mm ≤1000mm ≤1250mm

Take-up speed

 400m/min 400m/min 300m/min 200m/min

Take-up strength

 25N/M 25N/M 36N/M 50N/M

Take-up motor

 4KW 4KW 5.5KW 7.5KW

Cable way

Precision cable arranging device

Precision cable arranging device

Precision cable arranging device

Precision cable arranging device

Lifting of the reel

 Electric/hydraulic Electric/hydraulic Electric/hydraulic Electric/hydraulic

Cable clamping

 Pneumatic / hand crank Pneumatic / hand crank Pneumatic / hand crank Pneumatic / hand crank

5. QP 120 COILING MACHINE

qipang Automatic cable winding Machine wire rewinding machine coiling cable manufacturing equipment qipang Automatic cable winding Machine wire rewinding machine coiling cable manufacturing equipment

7. QP 630-1000 ACTIVE PAY OFF MACHINE

qipang Automatic cable winding Machine wire rewinding machine coiling cable manufacturing equipment qipang Automatic cable winding Machine wire rewinding machine coiling cable manufacturing equipment

Model

 QPF 800 QPF1000 QPF 1250 QPF 1500

Take-up line diameter

 ≤10mm ≤15mm ≤20mm ≤30mm

Wire reel

 φ630-φ800mm φ800-φ1000mm φ800-φ1250mm φ1000-φ1250mm

Speed of release

 ＜600r /min ＜500r /min ＜400r /min ＜400r /min

Take-up motor

 4KW 5.5KW 5.5KW 7.5KW

Lift motor

 0.75KW 1.5KW 1.5KW 1.5KW

Release force

 External force control External force control External force control External force control

Lifting of the reel

 Electric/hydraulic Electric/hydraulic Electric/hydraulic Electric/hydraulic

Cable clamping

 Pneumatic / hand crank Pneumatic / hand crank Pneumatic / hand crank Pneumatic / hand crank

8. QP 630-1000 PASSIVE PAY OFF MACHINE

qipang Automatic cable winding Machine wire rewinding machine coiling cable manufacturing equipment qipang Automatic cable winding Machine wire rewinding machine coiling cable manufacturing equipment

Model Storage wheel diameter Number of reel wheels Storage line wire diameter
QP-0330V 300 10+11 41 2-6
QP-0335V 350 9+10 38 4-11
QP-0340V 400 7+8 30 6-12
QP-0345V 450 7+8 31 8-13
QP-0350V 500 6+7 24 10-15
QP-0360V 600 6+7 24 12-20

9. QP BIG WINDING MACHINE

qipang Automatic cable winding Machine wire rewinding machine coiling cable manufacturing equipment qipang Automatic cable winding Machine wire rewinding machine coiling cable manufacturing equipment

Machine Type

 QP-2000 QP-2500 QP-3150 QP-3500 QP-4200 QP-4500 QP-5000

Applicable coil specifications

 PN1000-PN2000 PN1600-PN2500 PN1600-PN3150 PN2000-PN3500 PN2000-PN4200 PN2500-PN4500 PN3000-PN5000

Applicable coil width

 750-1500 1180-1900 1180-2300 1500-2300 1500-2400 1900-2500 1900-2500
Applicable cable outer diameter ≤25 ≤45 ≤80 ≤100 ≤120 ≤120 ≤150

Maximum load

 10T 12T 18T 20T 25T 30T 35T

Take-up speed

 6.2-25.6 4.9-20.6 3.3-13.8 3.3-13.8 3.3-13.8 3.3-13.8 3.3-13.8

Take-up motor (DC)

 5.5 5.5 7.5 7.5 7.5 11 11

10. QP- COUNTER METER

qipang Automatic cable winding Machine wire rewinding machine coiling cable manufacturing equipment qipang Automatic cable winding Machine wire rewinding machine coiling cable manufacturing equipment

11. QP- WINDING MACHINE EQUIPMENT

qipang Automatic cable winding Machine wire rewinding machine coiling cable manufacturing equipment qipang Automatic cable winding Machine wire rewinding machine coiling cable manufacturing equipment

Model A Type B Type
Release form Electric or passive Electric or passive

Release form

 ≤630mm ≤800mm

Cable way

 Automatic cable Automatic cable

Number of wire grooving

 3 groove 3 groove

Wire tie height

 30-100mm 30-100mm

Wire tie outer diameter

 ≤310mm ≤400mm
Wire inner diameter φ115mm-φ120mm-φ125mm

φ130mm- φ135mm-

φ140mm--φ145mm

Host revolutions

 0-500RPM/min 0-360RPM/min

monitor rate

 2.2KW 4KW

Production per shift

 700 t / 8 hours 400 t / 8 hours
Loop diameter

BV,BVV,RV:0.3-6㎡

RVV,RVVP: ＜8mm

SYV75-3, SYV75-5 Coaxial

BV,BVV,RV:1-25㎡

RVV,RVVP: ＜12mm

SYV75-5, SYV75-9 Coaxial
Meter counter Electronic high precision (adjustable length of meters) Electronic high precision (adjustable length of meters)

Upper plate device

 Lever type Lever type


12. QP- CABLE COILING AND PACKING MACHINE

qipang Automatic cable winding Machine wire rewinding machine coiling cable manufacturing equipment qipang Automatic cable winding Machine wire rewinding machine coiling cable manufacturing equipment

Machine Type Height Out diameter(MM) Inner Diameter(MM) Wire Diameter(MM) Packaging material Average line volume output speed
QP1040 50-100 170-220 120-140 2.5-12 PVC/PE 2-2.5 Volume/minute(100m)
QP1860 80-180 250-600 180-250 5-18 PVC/PE 1-1.5 Volume/minute(100m)
