Specifications
Brand Name :
QiPang
Model Number :
QP-5005
Certification :
CE
Place of Origin :
Shanghai
MOQ :
1
Price :
RMB/USD Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
50/Week
Delivery Time :
5-8days
Packaging Details :
cotton or wooden boxes
Name :
Working Frequency Copper Wire Preheater
Material :
Steel
Condition :
New
Function :
Wire Heat
Color :
White and black
Wrranty :
1year
Voltage :
220v
Service :
OEM/ODM
Description
Product Description
Working Frequency Copper Wire Preheater QP-5005 For Wire Heat Carry Out Accurate Temperature Control
Product description:
The power frequency preheater adopts the principle of induction heating and is suitable for on-line annealing and preheating of various metal conductors. In the production line, the adhesion between the outside and the conductor can be obviously improved. During the preheating process, the preheating temperature of more than 100 makes the water on the conductor evaporate, the molecular structure of the object is activated and soft, and the quality of the external brightness, bubble and attachment structure is obviously improved. Compared with the oven heating pipe heating equipment, it saves more than 60% electricity. By using the induction heating principle, the electric spark damage to the wire rod is less, the resistance to the preheating conductor is small, it is not easy to stretch, and the output preheating automatic speed tracks to ensure the consistency of the temperature when the wire speed is different. Its appearance is beautiful, the use is convenient, the performance is stable, the price is economical, at present is the cable manufacturer uses the most extensive equipment.
Main technical parameters
Preheating capacity
Suitable line diameter
Adjustable using line speed
Preheating temperature
Guide wheel diameter
5KVA
0.5-2.5mm
300m/min
0-130C adjustable
195mm
Using three-phase
Ambient temperature
Related Model
AC380V 50HZ of Power supply
10-45C
QP-5008
QP-5010
QP-5015
195mm Guide Wheel 300m/Min 220v Copper Wire Preheater
