JZP-2.5B-SC Rubber Shock Absorber with Resonance Frequency 30 Hz Threaded Mounting and Bolt-on Installation
JZP-2.5B-SC Rubber Shock Absorber with Resonance Frequency 30 Hz Threaded Mounting and Bolt-on Installation
JZP-2.5B-SC Rubber Shock Absorber with Resonance Frequency 30 Hz Threaded Mounting and Bolt-on Installation
JZP-2.5B-SC Rubber Shock Absorber with Resonance Frequency 30 Hz Threaded Mounting and Bolt-on Installation
JZP-2.5B-SC Rubber Shock Absorber with Resonance Frequency 30 Hz Threaded Mounting and Bolt-on Installation
JZP-2.5B-SC Rubber Shock Absorber with Resonance Frequency 30 Hz Threaded Mounting and Bolt-on Installation
Specifications
Brand Name :
Hoan
Model Number :
JZP-2.5B-SC
Place of Origin :
China
MOQ :
4
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Feature :
Vibration Isolation
Mounting Type :
Threaded
Installation Method :
Bolt-on
Resonant Frequency :
5-10HZ
Compatibility :
Universal
Color :
Black
Compression :
Customized
Resonance Frequency :
30 Hz
Vibration Isolation :
Up to 90%
Application :
Automotive, Machinery, Industrial Equipment
Relative Product :
Backdraft Damper
Description
JZP-B-SC Series Rubber Shock Absorber for On-Vehicle Electronic Equipment
Redefine the Stable Foundation for On-Vehicle Electronic Equipment

Xi'an Hoan's JZP Series Vibration Isolators provide unmatched stability for sophisticated electronic equipment in special-purpose vehicles, including emergency rescue, mobile broadcasting, communication, and environmental monitoring platforms.

Advanced Vibration Isolation Technology
  • Breaks the fatal energy transmission path of traditional rigid connections
  • Modular structure with high-performance elastic damping materials
  • Creates a low-pass filter effect for near-static microenvironment
  • Prevents loose screws, solder joint cracks, and component failure
Precision Design for Broad Applications

The JZP Series offers multiple models with varying load-bearing capacities and natural frequencies to precisely match equipment requirements, from lightweight data collectors to heavy cabinet-type servers.

  • Simple modular installation requiring no complex tools
  • Rapid deployment on vehicle chassis or brackets
  • Improves equipment integration efficiency and reliability
Dimension Parameters
JZP-2.5B-SC Rubber Shock Absorber with Resonance Frequency 30 Hz Threaded Mounting and Bolt-on Installation
Model D (mm) H±1 (mm) h (mm) A±0.2 (mm) B (mm) d d2 R B (mm)
JZP-B-SC 46 30 21 40 50 M4 ∅5.5 5 22
Technical Parameters
Model Nominal Load (kg) Static Displacement (mm) Working Temperature (℃) Resonance Frequency (Hz) Impact Test Valid Period (year)
JZP-1.0B-SC 1.0 ≤0.3 -45～+65 41.5±5 100G12times 8
JZP-1.5B-SC 1.5 Same as above
JZP-2.0B-SC 2.0 Same as above
JZP-2.5B-SC 2.5 Same as above
JZP-3.0B-SC 3.0 Same as above
JZP-3.5B-SC 3.5 Same as above
JZP-4.0B-SC 4.0 Same as above
JZP-5.0B-SC 5.0 Same as above
JZP-5.5B-SC 5.5 Same as above
JZP-6.0B-SC 6.0 Same as above
Performance Curves
Vibration Performance
JZP-2.5B-SC Rubber Shock Absorber with Resonance Frequency 30 Hz Threaded Mounting and Bolt-on Installation
Impact Performance
JZP-2.5B-SC Rubber Shock Absorber with Resonance Frequency 30 Hz Threaded Mounting and Bolt-on Installation
