JZP-3.0B-SC Rubber Shock Absorber with 3Kg Max Static Load 5-50Hz Vibration Frequency and 1 Year Warranty for Extreme Conditions
JZP-3.0B-SC Rubber Shock Absorber with 3Kg Max Static Load 5-50Hz Vibration Frequency and 1 Year Warranty for Extreme Conditions
JZP-3.0B-SC Rubber Shock Absorber with 3Kg Max Static Load 5-50Hz Vibration Frequency and 1 Year Warranty for Extreme Conditions
JZP-3.0B-SC Rubber Shock Absorber with 3Kg Max Static Load 5-50Hz Vibration Frequency and 1 Year Warranty for Extreme Conditions
JZP-3.0B-SC Rubber Shock Absorber with 3Kg Max Static Load 5-50Hz Vibration Frequency and 1 Year Warranty for Extreme Conditions
JZP-3.0B-SC Rubber Shock Absorber with 3Kg Max Static Load 5-50Hz Vibration Frequency and 1 Year Warranty for Extreme Conditions
Specifications
Shape :
Cylindrical
Color :
Black
Max Static Load :
3Kg
Vibration Frequency :
5-50Hz
Corrosion Resistance :
Resistant to corrosion
Mounting Type :
Threaded
Characteristic :
wide working frequency, long life span
Machinery Test Report :
Not Available
Natural Frequency :
7Hz-15Hz
Easy Installation :
Simple And Easy To Install
Material :
Rubber
Feature :
Vibration isolation
Warranty :
1 Year
Vibration Reduction :
High
Brand Name :
Hoan
Model Number :
JZP-3.0B-SC
Place of Origin :
China
MOQ :
4
Payment Terms :
L/C,D/A,D/P,T/T,,MoneyGram
Description
JZP-3.0B-SC Engineered for Extreme Conditions - The Best Rubber Shock Absorber for Mining Vehicles
JZP-B-SC Series
Tenacious Protection, Fearless of Rough Terrain - The Outstanding Performance of Xi'an Hoan's JZP Series Under Severe Road Conditions
Not all vehicles travel on smooth highways. vehicles, emergency rescue vehicles, mining trucks, and geological exploration vehicles often operate in extreme conditions. Muddy roads, potholes, and gravel paths create high-intensity impacts that test equipment durability. The JZP Series On-Vehicle Modular Vibration Isolators are specifically engineered to protect equipment in these harsh environments.
Shock Isolation: Protection Beyond Conventional Vibration
Unlike steady vibration, shock is an instantaneous, high-energy excitation that can cause structural damage. The JZP Series is designed with shock isolation as a core performance feature. Its damping materials and structural design extend impact duration through large deformation, significantly reducing peak acceleration (G-force) transmitted to equipment. When a vehicle hits a deep pothole, the JZP Series acts like an "airbag" for the equipment, absorbing most damaging forces.
Durability and Environmental Adaptability
In harsh environments like sandstorms, rain, snow, and salt spray, vibration isolator durability is crucial. The JZP Series uses high-quality weather-resistant materials with advanced surface treatments (galvanizing and Dacromet coating) for excellent corrosion resistance and anti-aging properties. These isolators resist both mechanical stress and chemical/environmental erosion, offering a service life far exceeding ordinary products.
Dimension Parameters
JZP-3.0B-SC Rubber Shock Absorber with 3Kg Max Static Load 5-50Hz Vibration Frequency and 1 Year Warranty for Extreme Conditions
Model D (mm) H±1 (mm) h (mm) A±0.2 (mm) B (mm) d d2 R B (mm)
JZP-B-SC 46 30 21 40 50 M4 ∅5.5 5 22
Technical Parameters
Model Nominal Load (kg) Static Displacement (mm) Working Temperature (℃) Resonance Frequency (Hz) Impact Test Valid Period (year)
JZP-1.0B-SC 1.0 ≤0.3 -45～+65 41.5±5 100G12times 8
JZP-1.5B-SC 1.5
JZP-2.0B-SC 2.0
JZP-2.5B-SC 2.5
JZP-3.0B-SC 3.0
JZP-3.5B-SC 3.5
JZP-4.0B-SC 4.0
JZP-5.0B-SC 5.0
JZP-5.5B-SC 5.5
JZP-6.0B-SC 6.0
Vibration and Impact Performance
Vibration Performance Curve
JZP-3.0B-SC Rubber Shock Absorber with 3Kg Max Static Load 5-50Hz Vibration Frequency and 1 Year Warranty for Extreme Conditions
Impact Performance Curve
JZP-3.0B-SC Rubber Shock Absorber with 3Kg Max Static Load 5-50Hz Vibration Frequency and 1 Year Warranty for Extreme Conditions
