JZP-6.0B-SC Hot Product 2024 Rubber Shock Absorber with 6.7KG Load Range and Condition Monitoring
JZP-6.0B-SC Hot Product 2024 Rubber Shock Absorber with 6.7KG Load Range and Condition Monitoring
JZP-6.0B-SC Hot Product 2024 Rubber Shock Absorber with 6.7KG Load Range and Condition Monitoring
JZP-6.0B-SC Hot Product 2024 Rubber Shock Absorber with 6.7KG Load Range and Condition Monitoring
JZP-6.0B-SC Hot Product 2024 Rubber Shock Absorber with 6.7KG Load Range and Condition Monitoring
JZP-6.0B-SC Hot Product 2024 Rubber Shock Absorber with 6.7KG Load Range and Condition Monitoring
Specifications
Brand Name :
Hoan
Model Number :
JZP-6.0B-SC
Place of Origin :
China
MOQ :
4
Payment Terms :
L/C,D/A,D/P,T/T,,MoneyGram
Isolation Frequency :
5Hz
Durability :
High
Temperature Range :
Wide
Usage :
Absorbing shocks and vibrations
Color :
Black
Product Certification :
ISO 9001
Load Range :
6,7KG
Appliocation :
Autos, Machinery,Engines
Product Keywords :
Friction damping isolators
Installation Type :
Horizontal/Vertical
Cost :
Affordable
Marketing Type :
Hot Product 2024
Resonance Frequency :
30 Hz
Showroom Location :
None
Description
JZP-6.0B-SC High-Performance Vibration Isolation and Condition Monitoring for Rubber Shock Absorber
JZP-B-SC Series
Towards the Future: Development Prospect of the JZP Series and Intelligent Vibration Isolation Technology
Technology knows no bounds. Xi'an Hoan Microwave Co., Ltd. continues to invest heavily in R&D, focusing on emerging demands for future on-vehicle vibration isolation technology. The JZP Series platform is evolving towards smarter, more integrated, and more active solutions.
Intelligent Vibration Isolation and Condition Monitoring
Future generations of the JZP Series may integrate micro MEMS accelerometers and IoT modules, enabling real-time monitoring of vibration isolation status and equipment vibration magnitude. This data can be uploaded to cloud platforms via wireless networks, supporting predictive maintenance, fleet management optimization, and vehicle Prognostics and Health Management (PHM).
Active and Semi-Active Vibration Isolation Technologies
For ultra-high vibration isolation requirements—such as on-vehicle lithography machines and quantum communication devices—Xi'an Hoan is exploring active/semi-active vibration isolation technologies. Using sensors, controllers, and actuators, this system can achieve precise control over specific frequency vibrations, especially low-frequency ones.
Dimension Parameter Table
JZP-6.0B-SC Hot Product 2024 Rubber Shock Absorber with 6.7KG Load Range and Condition Monitoring
Model D (mm) H±1 (mm) h (mm) A±0.2 (mm) B (mm) d d2 R B (mm)
JZP-B-SC 46 30 21 40 50 M4 ∅5.5 5 22
Technical Parameter Table
Model Nominal Load (kg) Static Displacement (mm) Working Temperature (℃) Resonance Frequency (Hz) Impact Test Valid Period (year)
JZP-1.0B-SC 1.0 ≤0.3 -45～+65 41.5±5 100G12times 8
JZP-1.5B-SC 1.5
JZP-2.0B-SC 2.0
JZP-2.5B-SC 2.5
JZP-3.0B-SC 3.0
JZP-3.5B-SC 3.5
JZP-4.0B-SC 4.0
JZP-5.0B-SC 5.0
JZP-5.5B-SC 5.5
JZP-6.0B-SC 6.0
Vibration and Impact Curve of JZP-B-SC Series
Vibration
JZP-6.0B-SC Hot Product 2024 Rubber Shock Absorber with 6.7KG Load Range and Condition Monitoring
Impact
JZP-6.0B-SC Hot Product 2024 Rubber Shock Absorber with 6.7KG Load Range and Condition Monitoring
