30*60*1.6mm Oval Pipe economic Full Welded Used Horse Corral Panels For Farm
30*60*1.6mm Oval Pipe economic Full Welded Used Horse Corral Panels For Farm
30*60*1.6mm Oval Pipe economic Full Welded Used Horse Corral Panels For Farm
30*60*1.6mm Oval Pipe economic Full Welded Used Horse Corral Panels For Farm
30*60*1.6mm Oval Pipe economic Full Welded Used Horse Corral Panels For Farm
30*60*1.6mm Oval Pipe economic Full Welded Used Horse Corral Panels For Farm
30*60*1.6mm Oval Pipe economic Full Welded Used Horse Corral Panels For Farm
30*60*1.6mm Oval Pipe economic Full Welded Used Horse Corral Panels For Farm
Specifications
Brand Name :
wiremeshfence.com/buy-farm_fence.html
Model Number :
1.6m 1.8m height 5 bar 6 bars
Certification :
ISO
Place of Origin :
American Design China Made
MOQ :
500 liner meter
Price :
8.88$ per liner meter
Payment Terms :
TT30% deposit balance 70% at sight of finished products
Supply Ability :
10000 liner meters
Delivery Time :
7 work days
Packaging Details :
All metal Pallets
Materials :
Q235 steel pre hot dipped galvanized steel pipe
Color :
Any Ral Color
Treatment :
Hot Dipped Glavanized,Powder Coated
Thickness :
1.2-2.5mm
Type :
Weld panels
Warranty :
5 -25 years depand on the treatment
Main Market :
Oceania Europea ,Middle East ,USA ,AU etc
Accessoires :
U and L lugs
Customized :
Available
Sample :
Free but pay freight cost
Square pipes :
40*40mm*1.6mm,50*50*1.6m
Round Pipes :
32mm,42mmO.D,1.6mm thick
Oval Pipes :
30*60*1.6mm,40*80*1.6mm
Height :
1.6m high with 5 bars,1.8m
Name :
Heavy duty galvanized livestock panel ,cattle panel ,horse pane, ,sheep panels
Stanard Size :
1800x2100,1600mm x 2100mm
Description

30*60*1.6mm Oval Pipe economic Full Welded Used Horse Corral Panels For Farm

We could supply two types of farm gate to satisfy different markets:welded wire mesh farm gate and steel pipe farm gate.
Steel pipe farm gate
Type
Light-Duty
Medium-Duty
Heavy- Duty
Rail Number
(Height)
5 Rails 1600mm
6 Rails 1700mm
6 Rails 1800mm
5 Rails 1600mm
6 Rails 1700mm
6 Rails 1800mm
5 Rails 1600mm
6 Rails 1700mm
6 Rails 1800mm
Post Size
40 x 40mm RHS
40 x 40mm RHS
50 x 50mm RHS
50 x 50mm RHS
89mm OD
60 x 60mm RHS
Rail Size
40 x 40mm
60 x 30 mm
50 x 50mm
80x 40mm
97 x 42 mm
115 x 42mm
Length
2.1m2.2m 2.5m 3.2m 4.0m etc.
Surface Treatment
1. Fully hot dipped galvanized 2. Pre- Galvanized pipe then antirust spraying
Kits
1. 2 Lugs and Pins
2. Cattle Panel Gate (Cattle Gate In Frame, Double Gate, Man Gate, Slide Gate)
30*60*1.6mm Oval Pipe economic Full Welded Used Horse Corral Panels For Farm
30*60*1.6mm Oval Pipe economic Full Welded Used Horse Corral Panels For Farm
Welded wire mesh farm gate
Frame:33.4*2mm ,32mm*2.0mm round tube
Bracing tube:30*2mm,25mm*2.0mmround tube
Mesh:200*100*5mm
Length1.17m
Height:3,4,6,8,10,12,14,16feet
30*60*1.6mm Oval Pipe economic Full Welded Used Horse Corral Panels For Farm
30*60*1.6mm Oval Pipe economic Full Welded Used Horse Corral Panels For FarmFeature
1.Easy fast to handle (set up, remove and put down), very flexible.
2. Locking system makes the gate very stable quality steel and fully welding makes the gate panel more stronger, heavy duty and anti-broken. high zinc or pvc coated make the fence durable.
3. Environment protecting: connection with fittings and joining pins.
4. Livestock protection: no sharp edge, very smooth welding spot finished.
5. Cost-effective: give your farm yard years of service and minimal maintenance at a low initial cost.
30*60*1.6mm Oval Pipe economic Full Welded Used Horse Corral Panels For Farm30*60*1.6mm Oval Pipe economic Full Welded Used Horse Corral Panels For Farm
Corner of warehouse
30*60*1.6mm Oval Pipe economic Full Welded Used Horse Corral Panels For Farm30*60*1.6mm Oval Pipe economic Full Welded Used Horse Corral Panels For FarmPackage
30*60*1.6mm Oval Pipe economic Full Welded Used Horse Corral Panels For Farm30*60*1.6mm Oval Pipe economic Full Welded Used Horse Corral Panels For Farm30*60*1.6mm Oval Pipe economic Full Welded Used Horse Corral Panels For Farm
Specification:
Oval tube
30*60*1.6mm,40*80*1.6mm
Post
40*40*1.6mm,50*50*1.6mm
Rail
4-6 pieces
Size
2.1*1.8m,3*1.8m,3*1.6m
surface
hot dipped galvanized then silver painted
Square tube
40*40mm 50*50mm
Thickness
1.6mm,2mm
Rail
4-6 pieces
surface
hot dipped galvanized then silver painted
Round pipe
32mm,42mm
Thickness
1.6mm,2mm
Rail
4-6 pieces
Size
2.1*1.8m,
surface
hot dipped galvanized then silver painted
ITEM#
Description
Cattle panel(TYPE60x30)
Post:40x40x2mm Rail:60x30x2mm
Cattle swing gate
Size:2200(H)x2000mm(W)
Pipe:40x40x2mm
Inner pipe:60x30x2mm 50KG
Cattle swing gate
Size:2200(H)x2000mm(W)
Pipe:50x50x2mm
Inner pipe;80x40x2mm 65KG
Cattle sliding gate
Size;2200(H)x800mm(Inner W)
Frame:50x50x2mm 60KG
Cattle man gate
Size:2200(H)x750mm(Inner W)
Pipe:50x50x2mm
Cattle vet crush
Size:3050(L)x2100(H)x1520(overhead W)x800(bottom W)mm
Cattle ramp
Size:3200(L)x750(Inner W)mm
Sheep panel
Size:2800(L)x1000(H)mm
Pipe:40x40x2mm Rail:60x30x2mm
Sheep gate
Size:2000(L)x1000(H)
Pipe:40x40x2mm Rail:60x30x2mm


Description:

Our product is all first-grade material(hot dipped galvanized pipe), we use 3 different size material for the rail in our cattle yard panel and gate. Our standard galvanized cattle panel have six rails and are 2.1m long and 1.8m high. We can also manufacturer cattle panel to customer length or height. Stockyard sheep yard panels, like our lowes cattle gate, are priced complete with our low noise cleating system, our unique joining pins. galvanized post caps galvanized footplates.
Application:

Cattle Yards don’t need to be large or complicated but bear in mind the following:
  • Yards should be centrally located to allow easy mustering from all parts of the property
  • Yards should be accessible to vehicles by a good all-weather road
30*60*1.6mm Oval Pipe economic Full Welded Used Horse Corral Panels For Farm
30*60*1.6mm Oval Pipe economic Full Welded Used Horse Corral Panels For Farm
30*60*1.6mm Oval Pipe economic Full Welded Used Horse Corral Panels For Farm

Advantage:

1>360 degrees full welded technology
2>polish welding slag
3>wipe anti rust painted
4>silver painted

30*60*1.6mm Oval Pipe economic Full Welded Used Horse Corral Panels For Farm

Package:

Metal pallet+plastic film+bandage
Save more space for clients


Q: Can u supply a drawing?
A: Yes, we have a professional drawer, according to your demand give u a drawing.

Q: Is the panel strong?
A: Yes, adapt 360 full degrees welded technology, the panel can live 15 years in outdoor.

Q: How about the zinc for per sq?
A: The material is 40-60g zinc hot dipped galvanized tube.

Q: Why the surface is silver painted?
A: Because it is can recycle used, and the surface is bright smooth.
