Manual Tool Trap Wireline Pressure Control Equipment 2.5 Inch
Manual Tool Trap Wireline Pressure Control Equipment 2.5 Inch
Specifications
Brand Name :
Ruixin
Model Number :
2inch ID 2.5inch ID 3inch ID 4inch ID
Certification :
API
Place of Origin :
China Baoji
MOQ :
1
Payment Terms :
T/T
Supply Ability :
1 set 3 weeks
Delivery Time :
3-4 weeks
Packaging Details :
Wooden Box
Name :
Tool Trap Wireline Pressure Control Equipment
Size :
2inch 2.5inch 3inch 4inch
Material :
Alloy Steel
I.D. :
2.5 inch~6.38 inch
Use :
Wireline &Slickline
Control Tyoe :
Manual
Work Pressure :
3k 5k 10k 15k
Service :
Standard&H2S
Description

Tool Trap Wireline Pressure Control Equipment

I. Product brief description:
Anti-drop device, also known as the next catcher. It is a safety device to prevent the tool string from accidentally falling into the well when the tool string is lifted out. It is installed below the blowout prevention pipe and above the blowout prevention valve.
II. Main technical parameters:

Number Specification Pressure rating
1 2inch 35MPa, 70 MPa
2 2.5inch 35MPa, 70 MPa
3 3inch 35MPa, 70 MPa
4 4inch 35MPa, 70 MPa

Note: The specifications not listed in the above table can be provided according to customer needs
III. daily maintenance:
1. Do product test every time before going to the well;
2. After each use,
(1). Check whether the o-ring is damaged and replace it in time;
(2). Check whether the manual fork is flexible;
3. When not in use temporarily, you should bring the protective wire for storage.

Welcome to contact us at any time.
