Specifications
Brand Name :
TeXin OEM
Model Number :
TX-S050L
Certification :
CE ISO
Place of Origin :
Shenzhen ,China
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T,
Supply Ability :
100000/month
Delivery Time :
Within 3 work days
Packaging Details :
Durable case or box
Function :
Jamming signal frequency
Warranty :
1 Years
Power :
50W
Gain :
47dbi
Weight :
249G
Size :
125*60*17mm
Vibration need :
Car load OK
Description

TX long range 50W ldmos circulator S band gps GNSS signal blocker rf anti drone jammer module

TX-S050L anti drone jammer module is long distance high efficitive RF output power to shield drone signal 800mhz 900mhz 2400mhz 5200mhz 5800mhz ,etc. And the jamming distance is up to100-1000 square meters ,which depends on the real environment and drone signal jammer system .can be applied for family , workplace , library , class rooom , examination room ,prison, etc .

Product Feature
1. LDMOS chips support high output 50W
2.Using Aluminum alloy shell to endure high temperature environment
3. Circulator designed that can protection with high power operating

4. Jamming signal bands support customization according to personal requests

5. Shielding distance and range can install by self very convenient .

Attention

1.Power supply better carry about 28V 6.75A when itself 4.5A for its stable work

2.Heat dissipation measure is necessary including the thermal glue, suitable-size heat sink and cooling fans

3. Antenna or Load must be firstly connected before the power supply is ON or it will be short wire

Specifications :

No. Item Data Unit
1 Frequency (Customized) MHz
2 Test voltage 28 V
3 Current 4.5 A
4 Output 50 W
5 Gain 47 dB
6 Output stability 1 dB
7 Connector SMA/ Female
8 Output connector VSWR ≤1.30 (No power and VNA test)
9 Power supply wire Red+Black+Enable wire
10 Enable Control High ON Low Off
11 Out shell Size 125*60*17 mm
12 Mount hole 120*53 mm
13 Weight 249 g
14 Work Temperature -40~+65 ℃
15 Out shell material Aluminum
16 Vibration need Car load OK

Pictures :

TX long range 50W ldmos circulator S band gps GNSS signal blocker rf anti drone jammer moduleTX long range 50W ldmos circulator S band gps GNSS signal blocker rf anti drone jammer module

TX long range 50W ldmos circulator S band gps GNSS signal blocker rf anti drone jammer module
