High Gain 7-Band PCB Antenna Directional 433M/900M/1.2G/2.4G/5.8G for High Efficiency Signal Transmission

Product Description

This PCB antenna is a combination of multiple band with the minimum Mutual-interference, the optimized transmission angle and the higher gain；

When connected to the power amplifier, it can high efficiently assist the power amplifier to transmit the boosting or jamming signal.

Product Features

1.High Efficiency & Low Loss

Adopts high-quality PCB design and premium RF materials for low signal attenuation and high transmission efficiency. Excellent impedance matching ensures stable performance even under long‑term high‑power use.
2.High Gain Performance
High‑gain directional design enhances signal transmission and reception distance, providing stronger signal strength and higher system sensitivity for long‑range applications.
3.Seven‑band Synthesis Technology
Supports 7 communication bands covering 2G, 3G, 4G, and 5G. Integrated structure reduces interference and replaces multiple single‑band antennas for easier integration.
4.High Reliability & Stability
Industrial‑grade construction with low VSWR and strong anti‑interference ability. Stable performance in complex environments, ensuring long‑term reliable operation.

Specification

Performance Parameter
Type Frequency
(Customized)		 Gain VSWR Horizontal
Beam width		 Vertical
Beam width
433MHz 428-438 MHz 1 dBi ≤1.5 75-90º 68-80º
900MHz 803-930 MHz 5 dBi 72-88º 57-74º
1.2G 1160-1280 MHz 8 dBi 62-75º 55-68º
1.4/1.5/1.6G 1160-1620 MHz 8 dBi 55-75º 52-68º
2.4G 2400-2500 MHz 16 dBi 48-58º 27-38º
5.2G 5100-5350 MHz 17 dBi 35-45º 27-38º
5.8G 5700-5900 MHz 17 dBi 35-45º 27-38º
Front-to-back ratio ≥18 dB
Input Impedance 50Ω
Maximum input 50W
Input connector type 086 cable 7pcs*SMS-J

Mechanical Parameter

Dimension(L*W*H) 284*97.5*60mm
Antenna weight(kg) 0.35kg
Work Humidity(％) 10%- 95%
Surface Color Black & grey color
Work temperature(ºC) -40～65 º

Ideal Applications

1.RF power amplifier module integration
  • 2.Signal amplification & countermeasure systems
  • 3.Drone & device signal management
  • 4.Industrial wireless communication testing
  • 5.R&D and engineering development projects
