Original VCO Chip 300MHz 600MHz 800MHz SM150 For Jammer Module Parts
Original VCO Chip 300MHz 600MHz 800MHz SM150 For Jammer Module Parts
Original VCO Chip 300MHz 600MHz 800MHz SM150 For Jammer Module Parts
Original VCO Chip 300MHz 600MHz 800MHz SM150 For Jammer Module Parts
Specifications
Brand Name :
TX
Model Number :
TX-E6
Certification :
ISO9001,SGS,CE
Place of Origin :
Shenzhen, China
MOQ :
1
Price :
Negotiated
Payment Terms :
L/C, D/A, D/P, T/T,
Supply Ability :
10000pcs per month
Delivery Time :
1-3 days
Packaging Details :
Durable case or box
Product Name :
Cell Phone Signal Jammer
Type :
Cell Phone Signal Jammer
Rang :
100-200 sqm
Size :
370*110*33mm
Weight :
2.3kg
Application :
school examination rooms, teaching classrooms, dormitories, various social examination centers
Color :
white/black
Warranty :
1 Year
Description

Original VCO chip 300MHz 600MHz 800MHz SM150 for jammer module parts

The VCO (Voltage Control Unit) is an indispensable component of an RF module, its main function being to up-convert (transmit) and down-convert (receive) RF signals. It is primarily used in base stations, mobile communications, and other RF equipment.

2. Product Specification

Parameter Mini Typical Max unit Remark
Working voltage (Vcc) 4.75 5.0 5.25 Vdc
Output Level 10 dBm Vcc = 5.0 V
Current consumption(Icc) -- 25 mA
Tuning sensitivity (average) 10 -- -- MHz/V Vt = 0.5~4.5 V
Tuning voltage (Vt) 0.5 -- 4.5 Vdc
Phase noise/carrier @1KHzOffset -- -65 dBc/Hz Vcc = 5.0 V, Vt = 2.5 V
@10KHzOffset -- -92 dBc/Hz Vcc = 5.0 V, Vt = 2.5 V
@100KHzOffset -- -120 dBc/Hz Vcc = 5.0 V, Vt = 2.5 V
@1MHzOffset -- -130 dBc/Hz Vcc = 5.0 V, Vt = 2.5 V
Oscillation frequency

--

175

--

--

135

--

 MHz

Vcc = 5.0 V, Vt = 0.5 V

Vcc = 5.0 V, Vt = 4.5 V
Tuning terminal capacitance -- 56 -- pF
Second Harmonic -- -- -15 dBc
Load impedance -- 50 -- Ω
Operating temperature -40 -- +85 °C

3. Feature

-Low noise;

-High frequency stability;

-Low voltage operation: +3.3 +5V;

-Operating temperature range: -40°C~+85°C;

-Small size.

4. Application

Original VCO Chip 300MHz 600MHz 800MHz SM150 For Jammer Module Parts

Original VCO Chip 300MHz 600MHz 800MHz SM150 For Jammer Module Parts
