Specifications
Brand Name :
TX TELSIG
Model Number :
TX-H8K
Certification :
SGS,ISO9001
Place of Origin :
China
MOQ :
1
Price :
Negotiation
Payment Terms :
T/T,Paypal, Etc.
Supply Ability :
100,000pcs/month
Delivery Time :
In 2 work day
Packaging Details :
Durable case or box
Name :
Omnidirectional Antenna
Gain(dBi) :
3.5±0.5dBi
VSWR :
＜2.0
Polarization :
Vertical
Horizontal Beam width(0º) :
360º
Vertical Beam width(0º) :
55±5º
Ovality(dB) :
≤±2dB
Input Impedance（Ω） :
50Ω
Maximum input power(W) :
50W
Input connector type :
Sma-K
Dimensions­mm(Height/Width/Depth) :
ɸ115*140mm
Description

433MHz / 900MHz / 1.2GHz / 1.5GHz / 2.4GHz / 5.2GHz / 5.8GHz Omnidirectional Antenna

1.Product Overview
Customization is supported to meet diverse project and application demands. It delivers stable and efficient signal transmission for vehicle-mounted, drone and industrial outdoor scenarios, with outstanding environmental adaptability and long service life.
Adopting high-quality radio frequency design, this antenna comes with steady gain of 3.5±0.5dBi and low VSWR ≤ 2, effectively reducing signal reflection and transmission loss. It applies vertical polarization design, with 360° horizontal beamwidth and 55°±5° vertical beamwidth, realizing full-angle coverage without blind areas. The ovality is controlled within ≤±2dB, ensuring balanced and uniform signal strength in all directions.
With standard 50Ω input impedance, maximum power endurance up to 50W and standard SMA-K connector, it is widely compatible with most RF communication devices and easy to connect and match.
Made of high-strength black ABS housing, the antenna features compact size of φ115×140mm and light weight of 0.35kg, easy for daily installation and fixation. It supports working temperature from -40°C to +55°C, and can resist strong wind up to 31m/s, perfectly adapting to high and low temperature, strong wind and other harsh outdoor environments.

Adopting machine mounting method, the structure is firm and anti-vibration, suitable for long-term outdoor and vehicle running use. Standard package is 20 pieces per carton with carton size 470×350×220mm, convenient for bulk transportation and warehouse storage.

2.Application Scope

  • Drone data transmission and video transmission system
  • Vehicle-mounted communication and signal enhancement equipment
  • Industrial IoT, outdoor monitoring and security communication
  • Wireless remote control, alarm and emergency communication system
  • Various wireless signal receiving and transmitting devices

3.Quality & After-sales Service

  • *100% full inspection before shipment, strict quality control
  • *Industrial grade production standard, stable performance and long service life
  • *Support sample order, small batch trial order and large batch wholesale
  • *Custom frequency, custom logo and custom appearance service available
  • *Professional after-sales team, timely response to technical support
  • *Long-term stable supply, fast delivery and sufficient inventory
