4 Station Valve 2km Wireless Irrigation Controller System Solar Supply
4 Station Valve 2km Wireless Irrigation Controller System Solar Supply
Specifications
Brand Name :
Lensen
Model Number :
LS-SVC04
Place of Origin :
China
MOQ :
2pcs
Price :
Negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
6000pcs/month
Delivery Time :
2-7 days
Packaging Details :
standard carton
Power output :
1W
Distance :
2km
Wireless technology :
RF
Station :
4
Valve type :
9-36V DC type valve(Pulse)
Solar supply OK :
support
Description

4 Station Valve 2km Wireless Irrigation Controller System Solar Supply

Lora based 4-station Wireless Irrigation Control System for 9-36V DC latching valve remote ON-OFF control

To use together with the conventional irrigation controller.

This solution is very easy to operate. You don’t need to change any program. Just give our LS-RDI08 transmitter digital inputs, it will control valve controllers ON-OFF.

Paramater of the Filed Valve Controller

Parameter
Power output: 1W
Power supply: 12.6V DC
Control distance: 2km LOS
Baud rate: 2400bps
Receiving sensibility: -123dBm@1200bps, -118dbm(9600bps)
Networking
Networking: Point to point and point to multipoint
Protocol: Modbus RTU protocol
Port Description
Input 5AI (4-20mA)
Output: 4 pulse output
Communication port TTL
Current
Transmit current: <400mA
Receiving current: <40mA
General
Frequency: 433MHz
Channel No: 16 channels, can change via DIP switch
Physical Properties
Dimension: 115×90×40(mm)
Antenna Connector: SMA,vehicle antenna with 1.5m cable
Temperature: -35℃~+75℃( industrial)
Mounting method: Standard 3.5 inch industrial guild rail

4 Station Valve 2km Wireless Irrigation Controller System Solar Supply

This solution, master side LS-RDI08 has 8 digital inputs, it’s OK to control 2 valve controllers. Each valve controller LS-RPO04 is OK to connect 4 valves. One main controller works with 2 valve controllers. The logic relation is fixed.
