Specifications
Brand Name :
Mini-Circuits
Model Number :
PMA2-43LN
Certification :
CE, GCF, ROHS
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T, Western Union,
Supply Ability :
1000pcs per month
Delivery Time :
3-5 working days after received the payment
Packaging Details :
Packed in original tray firstly ,then carton, at last Bubble bag for outer packing
Function :
Step-Up, Step-Down
Output Configuration :
Positive or Negative
Topology :
Buck, Boost
Output Type :
Adjustable
Number of Outputs :
1
Description

PMA2-43LN+ Ultra-Low Noise Amplifier for 0.5-4.3GHz 0.6dB Noise Figure 18dB Gain +35dBm OIP3 Single +5V Supply Internal Bias 2.9dB Return Loss & SOT-89 Package

Features

Ultra low noise figure, 0.46 dB typ. at 1.9 GHz

High IP3, +33 dBm typ. at 1.9 GHz

High Pout, P1dB +19.9 dBm typ. at 1.9 GHz

Small size, 2 x 2 x 1mm

Applications

Base station infrastructure

Portable Wireless

LTE

GPS

GSM

Airborne radar

Description

Mini-Circuits PMA2-43LN+ is an E-PHEMT* based, ultra-low noise MMIC amplifier with a unique combination of low noise and high IP3, making this amplifier ideal for sensitive, high-dynamic-range receiver applications. This design operates on a single +5V supply, is well matched for 50Ω systems, and comes in a tiny, low profile package, accommodating dense circuit board layouts.

INFORMATION

Category
Manufacturer
Mini-Circuits
Series
-
Packaging
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
Part Status
Active
Frequency
1.1GHz ~ 4GHz
P1dB
19.9dBm
Gain
12.9dB
Noise Figure
1.08dB
RF Type
GPS, GSM, Radar, LTE
Voltage - Supply
5V
Current - Supply
51mA
Test Frequency
1.9GHz
Mounting Type
Surface Mount
Package / Case
8-TFDFN Exposed Pad
Supplier Device Package
MC1631-1
Base Product Number
PMA2

Drawing

PMA2-43LN+ Ultra-Low Noise Amplifier for 0.5-4.3GHz 0.6dB Noise Figure 18dB Gain +35dBm OIP3 Single +5V Supply Internal Bias 2.9dB Return Loss & SOT-89 Package

Our advantage :phones, PDA's, notebook comput.ers

  • High quality products --- our offers are 100% new and original, ROHS
  • Competitive price --- good Purchase channels with good price.
  • Professional service --- strict quality testing before the shipment, and perfect after-sales service after the purchase.
  • Adequate inventory --- With the support of our strong Purchasing team,
  • Fast delivery --- we will ship the goods within 1-3 working days after the payment confirmed.

be sure to meet your need for all kinds of components. ^_^


Product List
Supply a Series of Electronic Components, full range of semiconductors, active & passive Components.We can help you to get all for bom of the PCB,IN a word, you can get one-stop solution here,


The offers including:
Integrated Circuit, Memory ICs, Diode, Transistor , Capacitor, Resistor, Varistor, Fuse, Trimmer & Potentiometer, Transformer, Battery, Cable, Relay, Switch, Connector, Terminal Block, Crystal & Oscillator, Inductor, Sensor, Transformer, IGBT Driver, LED,LCD, Convertor, PCB (Printed Circuit Board),PCBA (PCB Assembly)

Strong in Brand:
Microchip, MAX, AD, TI, ATMEL, ST, ON, NS, Intersil, Winbond, Vishay, ISSI, Infineon, NEC, FAIRCHILD, OMRON,YAGEO, TDK, etc
