Specifications
Private Mold :
Yes
Products Status :
Stock
Interface Type :
ESATA, Port RJ-45, usb
Brand Name :
HUA WEI, Huawei
Model Number :
5500 v6
Place of Origin :
Beijing, China
Products Status: :
Stock
Product name :
OceanStor 5500 V6
Supported Media :
3.5" HDD/SSD
RAID support :
RAID 0/1/5/6/10
Supported Storage Protocols :
NFS
health status :
100% healthy
Warranty :
3 Years
Port :
tianjin
Supply Ability :
10000 Piece/Pieces per Month
MOQ :
2 pieces
Price :
$9,999.00 - $99,999.00/pieces
Description
OceanStor Dorado 5500 V6 networking storage
Products Description

HW OceanStor Dorado 5500 V6 All Flash Storage Server with Supported Storage Protocols
HW OceanStor Dorado 5500 V6 All Flash Storage Server with Supported Storage Protocols
technical specifications
Model
OceanStor Dorado 5300 V6
OceanStor Dorado 5500 V6
OceanStor Dorado 5600 V6
Hardware Specification
Maximum cache (dual controllers with controller expansion)
256 GB -2 TB
768 GB -8 TB
384 GB -4 TB
Supported Storage Protocols
FC , ISCSI , FC - NVMe , NVMe over RoCE , NFS , CIFS , NDMP ,S3*
Front Channel Port Type
8/16/32 Gbit / s FC / FC - NVMe ,10/25/40/100 GbE 25/100 Gb NVMe over RoCE
Back Channel Port Type
100G RDMA / SAS 3.0
Maximum hot-swappable / number of O modules / controller enclosure
6
12
Maximum number of front-end host ports/controller enclosure
40
48
HDD type
1.92 TB /3.84 TB /7.68 TB /15.36/30.72 TB palm - sized NVMe SSD ,960 GB /1.92 TB /3.84 TB /7.68 TB /15.36 TB SAS SSD
Support SCM
800 GB /1.6TB SCM
Software Specification
RAID support
RAID 10°, RAID S , RAID 6, RAID - TP (tolerate 3 disk failures at the same time) and cross-frame RAID
storage management software
Device Management ( DeviceManager )
Multipath management (UltraPath)
Remote Maintenance Management ( DME IQ )
Electrical Specifications
power supply
SAS disk enclosure: 100V-240V AC ±10%,
192V-288V DC ,-48V--60V DC controller enclosure/smart NVMe disk enclosure:
200V-240V AC ±10%, 192V-288V DC .-48V--60V DC
SAS disk enclosure: 100V-240V AC ±10%, 192V~288V DC, -48V--60V DC Controller enclosure/smart NVMe disk enclosure: 200V-240V AC
±10%, 192V~288V DC, -48V--60V DC
weight
SAS controller enclosure s 30kg NVMe controller enclosure s 32kg SAS disk enclosure s 20kg Smart NVMe disk enclosure s 35kg
SAS controller box s 45kg NVMe controller s 50kg
SAS disk enclosure≤20kg Smart NVMe disk enclosure≤35kg
Working temperature
The ambient temperature at an altitude of ﹣60-+1800m is 5°C-35°C (cabinet)/40°C (frame);
When the altitude is 1800m-3000m, the ambient temperature (upper limit) will decrease by 1°C for every 220m increase in altitude.
Dimensions (H x W x D)
SAS controller enclosure 86.1mm x 447mm x 520mm NVMe controller enclosure＊86.1mm x 447mm x620mm
SAS controller box 86.1mm x 447mm x 820mm
NVMe controller frame＊86.1mm x 447mm x 920mm
SAS disk enclosure 86.1mmx447mm x 410mm Smart NVMe disk enclosure 86.1mmx447mmx620mm
SAS disk enclosure 86.1mmx447mm x 410mm Smart NVMe disk enclosure 86.1mmx447mmx620mm
