70KG Automatic Wire Bending Stripping Cutting Machine for 0.1-25mm2 Wires 10 Bending
70KG Automatic Wire Bending Stripping Cutting Machine for 0.1-25mm2 Wires 10 Bending
70KG Automatic Wire Bending Stripping Cutting Machine for 0.1-25mm2 Wires 10 Bending
70KG Automatic Wire Bending Stripping Cutting Machine for 0.1-25mm2 Wires 10 Bending
70KG Automatic Wire Bending Stripping Cutting Machine for 0.1-25mm2 Wires 10 Bending
70KG Automatic Wire Bending Stripping Cutting Machine for 0.1-25mm2 Wires 10 Bending
70KG Automatic Wire Bending Stripping Cutting Machine for 0.1-25mm2 Wires 10 Bending
70KG Automatic Wire Bending Stripping Cutting Machine for 0.1-25mm2 Wires 10 Bending
70KG Automatic Wire Bending Stripping Cutting Machine for 0.1-25mm2 Wires 10 Bending
70KG Automatic Wire Bending Stripping Cutting Machine for 0.1-25mm2 Wires 10 Bending
70KG Automatic Wire Bending Stripping Cutting Machine for 0.1-25mm2 Wires 10 Bending
70KG Automatic Wire Bending Stripping Cutting Machine for 0.1-25mm2 Wires 10 Bending
Specifications
Place of Origin :
Guangdong, China
Brand Name :
Yihan
Model Number :
YH-Z925
Usage :
Multifunctional, Bending Stripping and Cutting
Product name :
Wire bending machine
Stripping range :
0.1-25.0 mm2 BVV Cable
Stripping length :
Head 0 - 35mm Tail 0-30mm
Cutting Length :
1mm-99999.99mm
Catheter diameter :
1.5-12MM
Size :
530*470*340
Weight :
70KG
Number of bending :
10 (can add)
Bending length :
can adjust
Packaging Details :
Wooden package
Price :
$2,500.00/sets 1-2 sets
MOQ :
1 set
Description

70KG Automatic Wire Bending Stripping Cutting Machine for 0.1-25mm2 Wires 10 Bending70KG Automatic Wire Bending Stripping Cutting Machine for 0.1-25mm2 Wires 10 Bending70KG Automatic Wire Bending Stripping Cutting Machine for 0.1-25mm2 Wires 10 Bending

YH-Z925 Automatic used wire bending stripping and cutting machine suits for 0.1to 25mm2

Description:

  • This machine mainly for the automotive industry, sensor industry, power industry, electric control cabinet,
    a battery box line, Military factory,Robotics,Automation, Railways, off shore, Medical.
  • YH-Z906 machine can process whole electric wire according to required length,cut off and stripping head,not to hurt the tegument and conductor,high precision, thus greatly improving efficiency.
  • You are assured maximum flexibility and even more efficient way of meeting your wire processing need. Clockwise and counterclockwise, adjustable bending degree, 30degrees,45 degree, 60 degrees, 90 degrees. positive and negative two bending in one line.
Product Description
Product Name Automatic wire bending machine
Model YH-Z925
Dimension 600*550*450mm
Weight 55KG
Display method Chinese or English interface display
Power supply AC220/250V/50/60HZ
Capacity 180-600W
Cutting length 1mm-99999mm
Cutting Tolerance Adjustable
Peeling length 1.0mm-999.9mm(According to the wire)
Wire range 0.1-25.0mm2 BV hard wire cutting stripping and bending
Number of bending 10 times(more than 10 times is optional)
Productivity 800-1500pcs/h(according to the cutting length)
Cutting tolerances ±( 0.002* L : indicates a cutting length.
Drive mode Four simultaneously drive
Bending way Clockwise and counterclockwise,adjustable bending degree,30 degrees,45 degree,
60 degrees,90 degrees,positive and negative two bending in one line
Air supply 0.5-0.75MP

70KG Automatic Wire Bending Stripping Cutting Machine for 0.1-25mm2 Wires 10 Bending70KG Automatic Wire Bending Stripping Cutting Machine for 0.1-25mm2 Wires 10 Bending70KG Automatic Wire Bending Stripping Cutting Machine for 0.1-25mm2 Wires 10 Bending70KG Automatic Wire Bending Stripping Cutting Machine for 0.1-25mm2 Wires 10 Bending70KG Automatic Wire Bending Stripping Cutting Machine for 0.1-25mm2 Wires 10 Bending

Product Show
70KG Automatic Wire Bending Stripping Cutting Machine for 0.1-25mm2 Wires 10 Bending
Company profile

70KG Automatic Wire Bending Stripping Cutting Machine for 0.1-25mm2 Wires 10 Bending70KG Automatic Wire Bending Stripping Cutting Machine for 0.1-25mm2 Wires 10 Bending70KG Automatic Wire Bending Stripping Cutting Machine for 0.1-25mm2 Wires 10 Bending70KG Automatic Wire Bending Stripping Cutting Machine for 0.1-25mm2 Wires 10 Bending70KG Automatic Wire Bending Stripping Cutting Machine for 0.1-25mm2 Wires 10 Bending

Advantages

70KG Automatic Wire Bending Stripping Cutting Machine for 0.1-25mm2 Wires 10 Bending

Certification

70KG Automatic Wire Bending Stripping Cutting Machine for 0.1-25mm2 Wires 10 Bending

Packaging delivery

70KG Automatic Wire Bending Stripping Cutting Machine for 0.1-25mm2 Wires 10 Bending

Problem solving

70KG Automatic Wire Bending Stripping Cutting Machine for 0.1-25mm2 Wires 10 Bending

Contact us

70KG Automatic Wire Bending Stripping Cutting Machine for 0.1-25mm2 Wires 10 Bending
