Product Description:

Product Specifications
Wire Diameter Range: 0.15mm – 0.32mm (customizable)

Material Options:

Stainless Steel (304, 316, 316L) – Corrosion-resistant, high strength

Nickel & Nickel Alloys – Superior chemical resistance

Titanium & Titanium Alloys – Lightweight, extreme corrosion resistance

Monel & Inconel – High-temperature & sour gas resistance

Mesh Density: 10–200 PPI (Pores Per Inch) – Adjustable for flow vs. filtration precision

Filtration Grade: 5μm–1000μm – Depending on knitting pattern & layering

Key Features & Benefits
✔ High Porosity (30%-60%) – Optimized for low pressure drop & high flow rates
✔ 3D Interlocking Structure – Excellent dirt-holding capacity and mechanical stability
✔ Flexible & Resilient – Can be molded into tubes, discs, or custom shapes
✔ Multi-Layer Designs – Gradient filtration for extended service life
✔ Easy to Clean – Backflushable, chemical-resistant, and reusable

Technical Parameters
Parameter Specifications
Wire Diameter 0.15mm – 0.32mm (custom)
Material Options 304, 316L, Nickel, Titanium, Monel, Inconel
Filtration Range 5μm – 1000μm
Max Temperature -200°C to +650°C (material-dependent)
Max Pressure Up to 5MPa (50 bar) (reinforced designs available)
Shape Options Rolls, sleeves, tubes, discs, cartridges

Features:

• Product Name: Knitted Wire Mesh
• Width: 6MM-1000MM
• Model: 200-400
• Customized: Available
• Wires Dia: 0.15-0.32 MM
• Type: Round, Square Or Circle

Technical Parameters:

Applications:

With a delivery time of 20-25 days and payment terms of TT, XUWEI Knitted Wire Mesh guarantees timely fulfillment of orders. The product has a strong supply ability for filtration purposes in various industries, making it a valuable asset for businesses requiring efficient filtration solutions.

The XUWEI Knitted Wire Mesh has a filter efficiency of 93%, with mesh openings ranging from 0.5mm to 5mm. This product is widely used for air and liquid filtration, providing effective and reliable performance in diverse applications. The width of the mesh ranges from 6mm to 1000mm, catering to different filtration requirements.

Constructed with wires diameter between 0.15mm to 0.32mm, the XUWEI Knitted Wire Mesh offers durability and longevity in its performance. This Brass Knitted Wire Mesh is specifically designed for stainless gas-liquid filtration, ensuring optimal results in various scenarios.

Customization:

Product Customization Services for Knitted Wire Mesh:

Brand Name: XUWEI

Model Number: XW007

Place Of Origin: China

Certification: CE ISO9001

Minimum Order Quantity: 200 KG

Price: 10-15 USD

Packaging Details: Woven Box

Delivery Time: 20-25 Days

Payment Terms: TT

Supply Ability: Filtration In Various Industries

Width: 6MM-1000MM

Features: Flexible, Durable, Corrosion Resistant

Mesh Opening: 0.5mm-5mm

Weaving Type: Knitting

Usage: Used As Filtration Of Air And Liquid.

Support and Services:

Our Product Technical Support and Services for Knitted Wire Mesh include:

- Assistance with product selection based on your specific application requirements.

- Guidance on proper installation and usage of the knitted wire mesh.

- Troubleshooting support for any issues or concerns you may encounter.

- Recommendations for maintenance and care to ensure optimal performance of the product.

Packing and Shipping:

Product Packaging:

The knitted wire mesh will be carefully wrapped in protective plastic and placed in a sturdy cardboard box to prevent any damage during shipping.

Shipping:

We partner with reliable shipping companies to ensure your knitted wire mesh reaches you safely and on time. The product will be shipped with tracking information provided so you can monitor its journey to your doorstep.

FAQ:

Q: What is the brand name of this knitted wire mesh product?

A: The brand name is XUWEI.

Q: What is the model number of this knitted wire mesh product?

A: The model number is XW007.

Q: Where is this knitted wire mesh product manufactured?

A: This product is manufactured in China.

Q: What certifications does this knitted wire mesh product have?

A: It is certified with CE and ISO9001.

Q: What is the minimum order quantity for this knitted wire mesh product?

A: The minimum order quantity is 200 KG.
