New Energy Cable Extrusion Line with 80m/min Speed and φ120mm Specification for PVC, TPE, TPU, XLPO Materials
New Energy Cable Extrusion Line with 80m/min Speed and φ120mm Specification for PVC, TPE, TPU, XLPO Materials
Specifications
Design speed :
80m/min
Keyword :
Cable Extrusion Line
Applicable conductor core wire diameter :
φ1.5mm-φ20mm
screw L/D :
25/26:1
Maximum line speed :
Max 110m/min
Finished outer diameter :
φ2.5mm-φ25mm
Application :
PVC, TPE, TPU, XLPO
Place of Origin :
China
Brand Name :
Kunbo
MOQ :
1
Packaging Details :
Different packaging methods are adopted according to different modes of transport.
Payment Terms :
L/C,T/T,D/P,D/A
Name :
New Energy Extrusion Production Line
Main machine specifications :
φ80mm, φ90mm, φ120mm;
Description
New Energy Cable Extrusion Line 80m/Min Extrusion Production Line
Warranty & Installation Terms
  • Transportation expenses of replacement spare parts, transportation expenses, food and accommodation expenses of engineers shall be borne by the buyer
  • Buyer shall bear the cost of round-trip air ticket for first installation
  • Transportation, accommodation and food expenses of engineers in customer's country shall be borne by the buyer
  • All equipment, machinery, installation materials, labor, and translator charges are on buyer's account
  • On-site commissioning times: If travel is restricted, remote debugging via video conference will be provided
  • Estimated installation period: 7-10 days
Product Overview

Photovoltaic Wire String Extrusion One-Step Extrusion Production Line 200m/min

EV cables (electric vehicle high-voltage cables) are the core "blood vessels" of electric vehicle energy transmission, responsible for safely and efficiently transmitting high-current electrical energy between high-voltage batteries, drive motors, power electronic equipment (such as inverters, DC-DC converters) and charging interfaces. Their design is fundamentally different from ordinary automotive low-voltage cables and must meet stringent electrical, mechanical and environmental requirements.

Applications

Suitable for extrusion of insulation/sheath of:

  • PVC
  • TPE
  • TPU
  • XLPO
Main Process Parameters

Extrusion Materials: PVC, TPE, TPU, XLPE

Main Machine Specifications: φ80mm, φ90mm, φ120mm

Applicable Conductor Core Wire Diameter: φ1.5mm-φ20mm

Finished Outer Diameter: φ2.5mm-φ25mm

Maximum Line Speed: Max 110m/min

Model Adaptation Parameters
Screw Specification (mm) φ80 φ90 φ120
Maximum Screw Speed (rpm) 90 90 80
PVC Output (kg/h) 280 360 500
XLPE Output (kg/h) 150 180 250
Aspect Ratio (L/D) 25/26:1
Drive Power (kW AC) 75 90 160
Barrel Temperature Control Areas 5 5 6
