Specifications
private mold :
Yes
products status :
Stock
type :
Barcode Scanner
scan element type :
CMOS
colour depth :
32 Bit
interface type :
usb
max paper size :
n/a
optical resolution :
1280x800 Pix
scan speed :
350 scans/second
Brand Name :
winson
Place of Origin :
Guangdong, China
warranty(year) :
1-Year
after-sales service :
Call Center and on-line Technical Support
software development kit (sdk) :
NO
color :
Black
Interface :
USB HID Keyboard/USB VCP/RS232
Radio Range :
10m(30 feet)
View field :
DP:H:54°,H33°
Reading Accuracy :
DP:1D Linear:≥3 mils 2D:≥5 mils
Battery :
2500mAh rechargeable lithium battery
Communication :
BT 4.2,Class 2
Aiming light :
Red LED/White LED
Leakproofness Grade :
Scanner:IP67,Base:IP51
Certification :
ce, RoHS
Description
Product Description
Industry IP65 Rate High-speed 2D Wireless Scanner Barcode Reader Scanner for Warehouse Logistic
Industry IP65 Rate High-speed 2D Wireless Scanner Barcode Reader Scanner for Warehouse Logistic
Industry IP65 Rate High-speed 2D Wireless Scanner Barcode Reader Scanner for Warehouse Logistic
Industry IP65 Rate High-speed 2D Wireless Scanner Barcode Reader Scanner for Warehouse Logistic
Industry IP65 Rate High-speed 2D Wireless Scanner Barcode Reader Scanner for Warehouse Logistic
Industry IP65 Rate High-speed 2D Wireless Scanner Barcode Reader Scanner for Warehouse Logistic
Industry IP65 Rate High-speed 2D Wireless Scanner Barcode Reader Scanner for Warehouse Logistic
Industry IP65 Rate High-speed 2D Wireless Scanner Barcode Reader Scanner for Warehouse Logistic
Industry IP65 Rate High-speed 2D Wireless Scanner Barcode Reader Scanner for Warehouse Logistic
Industry IP65 Rate High-speed 2D Wireless Scanner Barcode Reader Scanner for Warehouse Logistic
Specification
Communications
Blue tooth4.2，Class 2
Radio Range
10m（30 feet）
Size
Scanner：92mmx75mmx184 mm(L*W*H) Base：221mm x89mm x 71mm(L*W*H)
Weight
Scanner：300g Base：220g
Input Voltage
DC 5V±5%
Working Current
450mA
Stand-by Current
100mA
Color
Blue+Black
Interface
USB HID Keyboard/USB VCP/RS232
Indicator
LED Indicator/Buzzer/Vibration
Battery
2500mAh rechargeable lithium battery
Full Charge Time
Whole machine charging time：5h Battery compartment time：3h
Lighting Source
Red LED/White LED
Aiming light
Single spot laser
Filed of view
Level：46°, Vertical：35°
Sensor Resolution
1280 *800 pixels
Min Print Contras
Min reflection difference 20%
Scan Angle
Tilt Angle：-60° to 0°，0° to +60° Skew Angle：-60° to 0°，0° to +60 Rotate Angle：-180° to0°，0 to +180°
Reading Accuracy
DP：1D Linear: ≥3 mils 2D ≥5 mils
Temperature
-20°C~50°C/-4°F ~122°F (Operating) -40°C~70°C/-40°F ~158°F(Storage)
Reading Accuracy
0-95%（No condensation）
Humidity
2500mAh rechargeable lithium battery
Drop Test
Scanner:Can withstand 50 times drops of
falling from 2 meters to concrete surface
Aiming light
Scanner: Can withstand 5000 rolls within 1 meter
Leakproofness
Grade
Scanner：IP67 Base
Barcode Reading
Distance Range
DP：
Code 39 ( 3 mil ) : 50 mm ~ 90 mm
Data (5 mil):45 mm ~ 100 mm
Data Matrix (10 mil) : 45mm~150 mm
QR ( 5 mil ): 45mm ~90 mm
QR (9 mil ) :45 mm ~ 120 mm
1D
UPC A , UPC ,EAN 8, EAN 13 , Code 128 , Code 39 ,
Code 93 , Codabar ,Plessey , MSI , Interleaved 2 of 5
2D
Data Matrix , QR , Micro QR
Environmental
parameters
Compliance with EU RoHS
Electrical Safety
EU Security Law：EN 62368-1：2014+EN 62479：2010 + ETSI
EN 301 489-1 V2.1.1（2017-02）+ ETSI 301 489-17 V3.1.1
（2017-02）+ETSI EN 300 328 V2.1.1（2016-11）
U.S. Security Law：FCC Part15 Subpart C 2018，Section15.247
