Communication mode | Wired transmission mode/ Wireless Read-time mode/Inventory mode/Cache mode |
Communication frequency | 2.402GHz - 2.480GHz ISM band |
Transmission range | 30m(In empty area ) |
Battery capacity | 2600mAh (Lithium battery) |
Charge Time from Empty to Full Charge | 6H |
Continuous working hours | 10H |
Memory | 100000 13 digit data barcodes |
Interface Supported | USB HID KEYBOARD/USB VCP |
Input Voltage | DC 5V±5% |
Current | Max:240mA |
Image Sensor | CMOS Array Sensor |
Sensor Resolution | 640 X 480 Pixels |
Light Source | white LED |
Aiming light source | RED LED |
Decoding speed | 60FPS |
Scanning Angle | Pitch angle:±60°;Skew angle:±60°;Tilt angle:±360° |
Field of View | 45.86H),35.21V) |
Min Resolution | 4mil |
Min .PCS value | ≥15% UPC/EAN 13(13mil) |
Language | Multiple Languages |
Data Edition | Support for custom data output |
