Rigid Type Cable Armouring Machine 400mm / 500mm Bobbin Size High Performance
Rigid Type Cable Armouring Machine 400mm / 500mm Bobbin Size High Performance
Rigid Type Cable Armouring Machine 400mm / 500mm Bobbin Size High Performance
Rigid Type Cable Armouring Machine 400mm / 500mm Bobbin Size High Performance
Rigid Type Cable Armouring Machine 400mm / 500mm Bobbin Size High Performance
Rigid Type Cable Armouring Machine 400mm / 500mm Bobbin Size High Performance
Rigid Type Cable Armouring Machine 400mm / 500mm Bobbin Size High Performance
Rigid Type Cable Armouring Machine 400mm / 500mm Bobbin Size High Performance
Specifications
Brand Name :
Herrman
Model Number :
JLK630
Certification :
ISO9001:2015,CE
Place of Origin :
China
MOQ :
1set
Price :
By Negotiation
Payment Terms :
L/C, T/T, D/A, D/P，By Negotiation
Supply Ability :
15 sets per month
Delivery Time :
90 working days
Packaging Details :
By seaworthy packing suitable for export
Name :
Rigid Type Armoring Machine
Function :
Cable armoring
Clamping type :
Pneumatic type clamping, Motor clamping, Manual Clamping
Bobbin Size :
400mm,500mm,630mm,710mm,800mm
Copper wire dia. :
1.2~5.0
Al wire dia. :
1.8~5.0
HS code :
847940
Color :
Color plate provided by customer
Bearing :
NSK
Motor :
SIEMENS
Warranty :
12 months
Description

Rigid type armoring machine rigid screening machine for power cable

Description

Rigid type armoring machine is used for steel wire armoring of power cable.

Technical Specification

1 Bobbin Size: 400mm,500mm,630mm,710mm,800mm

2 Bobbin QTY of Singe cage: From 6 bobbin to 48 bobbin

3 Clamping: Pneumatic type clamping, Motor clamping, Manual Clamping

4 Tension control: Hysteresis tension control, Mechanical tension control, Mechanical tension control with feedback, Pneumatic tension control

5 Bobbin Loading: Side-bottom Hydraulic loading, Side-bottom Electrical loading, Side loading

Main Specification

Bobbin Size Max. rotation speed(rpm) Wire dia.(mm)
6B 12B 18B 24B 30B 36B Aluminum Copper
500 273 225 198 173 151 120 1.8~5.0
242 199 175 153 133 96 1.2~5.0
630 Normal 218 189 166 146 130 103 1.8~5.0
190 167 147 129 115 82 1.2~5.0
High speed 310 290 250 215 185 135 1.8~5.0
210 195 170 145 128 108 1.2~5.0

Drawing for reference

Rigid Type Cable Armouring Machine 400mm / 500mm Bobbin Size High Performance
